Features Consumer Electronics Control (CEC) support: Yes Bidirectional: Yes Electrostatic Discharge (ESD) protection: Yes Type: AV transmitter & receiver HDCP version: 1.4/2.2 Plug and Play: Yes Material: Metal Bandwidth: 18 Gbit/s Maximum transfer distance: 150 m Cable types supported: Cat6, Cat7, Cat8, Cat5e Wall mountable: Yes Product colour: Black HDCP: Yes Maximum resolution: 3840 x 2160 pixels
Power Operating voltage: 24 V Power consumption (typical): 9.36 W Power over Ethernet (PoE): No Input current: 1 A
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Transmitter weight: 160 g Receiver dimensions (WxDxH): 65 x 140 x 18 mm Transmitter dimensions (WxDxH): 65 x 140 x 18 mm Receiver weight: 155 g
Packaging data Package weight: 1 kg Package depth: 185 mm Package width: 245 mm Quantity per pack: 1 pc(s) Package type: Box Package height: 75 mm
Ports & interfaces 3.5 mm (1/8-inch) out: Yes RS-232 output ports: 1 Remote (IR) output: 2 RJ-45 input ports: 1 USB ports quantity: 2 Serial interface type: RS-232 3.5 mm (1/8-inch) in: Yes HDMI in: 1 RS-232 input ports: 1 Serial ports quantity: 2 USB connector type: Micro-USB Remote (IR) input: 2 RJ-45 output ports: 1 Number of HDMI outputs: 1 DC-in jack: Yes Connectivity technology: Wired
