Processor
Processor boost frequency: 4.7 GHz
Processor cores: 10
Processor family: Intel® Core™ i5
Processor model: i5-14400F
Processor frequency: 1.8 GHz
Performance-core base frequency: 2.5 GHz
Efficient cores: 4
Performance cores: 6
Efficient-core base frequency: 1.8 GHz
Processor cache type: Smart Cache
Number of processors installed: 1
Processor manufacturer: Intel
Processor threads: 16
Processor socket: LGA 1700
Processor cache: 20 MB
Processor base power: 65 W
Processor generation: Intel® Core™ i5 (14th gen)
Maximum turbo power: 148 W
Efficient-core Max Turbo Frequency: 3.5 GHz
Performance-core Max Turbo Frequency: 4.7 GHz
Graphics
NVIDIA GameWorks VR: No
On-board graphics card model: Not available
Discrete graphics card model: Intel ARC B580
CUDA: No
NVIDIA G-SYNC: No
Discrete graphics card memory: 12 GB
Graphics card DisplayPorts quantity: 3
Number of discrete graphics cards: 1
Graphics card HDMI ports quantity: 1
Discrete GPU manufacturer: Intel
Discrete graphics memory type: GDDR6
On-board graphics card: No
Discrete graphics card: Yes
Memory
Maximum internal memory: 192 GB
Non-ECC: Yes
Memory channels: Dual-channel
Memory slots: 4x DIMM
Memory layout (slots x size): 2 x 16 GB
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Memory clock speed: 6000 MHz
Design
Product colour: Black
RGB backlighting: Yes
Refurbished: No
Number of 2.5" bays: 6
Viewing window: Yes
Number of 3.5" bays: 1
VESA mounting: No
Chassis type: Midi Tower
Water cooling system: No
Housing material: Metal, Plastic, Tempered glass
Power
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Bronze
Power supply: 600 W
Weight & dimensions
Weight: 10 kg
Depth: 429 mm
Height: 486 mm
Width: 228 mm
Network
Antenna type: 2x2
Ethernet LAN data rates: 1000, 2500 Mbit/s, 10, 100
Bluetooth: Yes
Bluetooth version: 5.2
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11b
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi: Yes
Internal components: ASUS TUF GAMING B760-PLUS WIFI / Intel ARC B580 / WD Blue SN5000 / ENDORFY Arx 500 ARGB
Performance
Audio output channels: 7.1 channels
Motherboard chipset: Intel B760
Motherboard form factor: ATX
Virtual Reality (VR) ready: Yes
Powered by: ENDORFY
Product type: PC
Market positioning: Gaming
Packaging content
Display included: No
Keyboard included: No
Mouse included: No
Expansion slots
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Optical drive type: No
Total SSDs capacity: 1 TB
Intel® Optane™ Memory module installed: No
Number of SSDs installed: 1
SSD interface: PCI Express
Total storage capacity: 1 TB
Storage media: SSD
SSD capacity: 1 TB
Number of storage drives installed: 1
Number of storage drives supported: 7
Card reader integrated: No
NVMe: Yes
SSD form factor: M.2
M.2 SSD size: 2280 (22 x 80 mm)
Ports & interfaces
S/PDIF out port: Yes
Ethernet LAN (RJ-45) ports: 1
Number of SATA III connectors: 4
USB 2.0 ports quantity: 1
DC-in jack: No
DisplayPorts quantity: 3
Combo headphone/mic port: No
Intel® Thunderbolt 5: No
Number of rear audio ports: 5
Number of front audio ports: 2
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Intel® Thunderbolt 4: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Microphone in: Yes
Number of front USB ports: 3
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Line-in: Yes
Line-out: Yes
HDMI ports quantity: 1
Fiber NIC port (Flex I/O): No
Number of rear USB ports: 6
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
Safety warning
Warnings: Ensure the unit is switched off and disconnected from the power source before carrying out any maintenance., Do not open the appliance housing without the appropriate tools and technical knowledge., Dispose of used electronic devices at specialised disposal facilities.
