Processor
Processor manufacturer: AMD
Processor socket: Socket AM5
Processor frequency: 4.2 GHz
Processor family: AMD Ryzen™ 7
Processor cache: 96 MB
Processor model: 7800X3D
Processor boost frequency: 5 GHz
Processor threads: 16
Processor cache type: L3
Processor cores: 8
Number of processors installed: 1
Processor generation: AMD Ryzen 7000 Series
Processor base power: 120 W
Graphics
NVIDIA GameWorks VR: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5080
CUDA: Yes
Discrete graphics card: Yes
On-board graphics card family: AMD Radeon Graphics
On-board graphics card: Yes
NVIDIA G-SYNC: Yes
Discrete graphics card memory: 16 GB
On-board graphics card model: AMD Radeon Graphics
Graphics card HDMI ports quantity: 1
On-board graphics card cores: 2
Graphics card DisplayPorts quantity: 3
AMD FreeSync: Yes
Number of discrete graphics cards: 1
Discrete GPU manufacturer: NVIDIA
On-board GPU manufacturer: AMD
Discrete graphics memory type: GDDR7
Memory
Maximum internal memory: 192 GB
Non-ECC: Yes
Memory channels: Dual-channel
Memory clock speed: 6000 MHz
Internal memory type: DDR5-SDRAM
Internal memory: 32 GB
Memory layout (slots x size): 2 x 16 GB
Internal memory manufacturer: Kingston
Memory slots: 4x DIMM
Design
Product colour: Black
VESA mounting: No
Chassis type: Midi Tower
Number of 2.5" bays: 4
Water cooling system: Yes
Number of 3.5" bays: 4
Refurbished: No
Viewing window: Yes
RGB backlighting: Yes
Housing material: Metal, Plastic, Tempered glass
Power
Power supply: 850 W
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Gold
Weight & dimensions
Height: 446 mm
Depth: 450 mm
Width: 285 mm
Weight: 15 kg
Network
Antenna type: 2x2
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet LAN data rates: 2500 Mbit/s, 100, 10, 1000
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Wi-Fi: Yes
Cabling technology: 10/100/1000Base-T(X)
Bluetooth version: 5.2
Internal components: ASUS TUF Gaming B650M-PLUS WIFI / NVIDIA GeForce RTX 5080 / Kingston Fury Beast RGB / WD Black SN850X / ASUS TUF Gaming LC II 360 ARGB/ ASUS TUF Gaming TF120 ARGB / ASUS TUF Gaming 850W / ASUS TUF Gaming GT502
Performance
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset: AMD B650
Market positioning: Gaming
Product type: PC
Powered by: ASUS
Virtual Reality (VR) ready: Yes
Packaging content
Mouse included: No
Display included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 4.x) slots: 1
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Optical drive type: No
Storage media: SSD
Number of storage drives supported: 6
Total storage capacity: 2 TB
Card reader integrated: No
NVMe: Yes
SSD interface: PCI Express
Intel® Optane™ Memory module installed: No
Number of storage drives installed: 1
Total SSDs capacity: 2 TB
Total HDDs capacity: 0 GB
SSD form factor: M.2
SSD capacity: 2 TB
Number of SSDs installed: 1
HDD capacity: 0 GB
M.2 SSD size: 2280 (22 x 80 mm)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
USB 2.0 ports quantity: 4
DVI port: No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
S/PDIF out port: Yes
DC-in jack: No
Microphone in: Yes
Number of SATA III connectors: 4
Combo headphone/mic port: Yes
HDMI ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
DisplayPorts quantity: 4
Number of front USB ports: 3
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Intel® Thunderbolt 4: No
Number of front audio ports: 1
Number of rear USB ports: 8
Intel® Thunderbolt 5: No
Line-in: Yes
Line-out: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Number of rear audio ports: 5
Fiber NIC port (Flex I/O): No
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
Safety warning
Warnings: Avoid contact with water or other liquids., If the battery is damaged or spilled, avoid contact with the material and contact service immediately., Do not open the computer case without disconnecting it from the power source.
