Processor
Processor model: 9800X3D
Processor threads: 16
Processor family: AMD Ryzen™ 7
Processor cache: 96 MB
Processor cache type: L3
Processor boost frequency: 5.2 GHz
Processor cores: 8
Processor frequency: 4.7 GHz
Processor generation: AMD Ryzen 9000 Series
Processor base power: 120 W
Number of processors installed: 1
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
NVIDIA GameWorks VR: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5080
Discrete graphics card memory: 16 GB
On-board graphics card model: AMD Radeon Graphics
CUDA: Yes
NVIDIA G-SYNC: Yes
Discrete GPU manufacturer: NVIDIA
AMD FreeSync: Yes
Graphics card DisplayPorts quantity: 3
Number of discrete graphics cards: 1
Discrete graphics memory type: GDDR7
Graphics card HDMI ports quantity: 1
On-board graphics card: Yes
On-board graphics card family: AMD Radeon Graphics
Discrete graphics card: Yes
On-board GPU manufacturer: AMD
On-board graphics card cores: 2
Memory
Non-ECC: Yes
Internal memory: 32 GB
Memory clock speed: 6000 MHz
Maximum internal memory: 192 GB
Internal memory type: DDR5-SDRAM
Internal memory manufacturer: Kingston
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Memory channels: Dual-channel
Design
Product colour: Black
Number of 2.5" bays: 4
Refurbished: No
Viewing window: Yes
Number of 3.5" bays: 4
Water cooling system: Yes
Chassis type: Midi Tower
Housing material: Metal, Plastic, Tempered glass
VESA mounting: No
RGB backlighting: Yes
Power
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Gold
Power supply: 850 W
Weight & dimensions
Weight: 15 kg
Width: 285 mm
Height: 446 mm
Depth: 450 mm
Network
Bluetooth: Yes
Ethernet LAN data rates: 10, 1000, 100, 2500 Mbit/s
Antenna type: 2x2
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Bluetooth version: 5.2
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Internal components: ASUS TUF Gaming B650M-PLUS WIFI / NVIDIA GeForce RTX 5080 / Kingston Fury Beast RGB / WD Black SN850X / ASUS Prime LC 360 ARGB / ASUS TUF Gaming TF120 ARGB / ASUS TUF Gaming 850W / ASUS TUF Gaming GT502
Performance
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Motherboard chipset: AMD B650
Powered by: ASUS
Virtual Reality (VR) ready: Yes
Market positioning: Gaming
Product type: PC
Packaging content
Keyboard included: No
Display included: No
Mouse included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 4.x) slots: 1
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Total storage capacity: 2 TB
Optical drive type: No
Storage media: SSD
Total HDDs capacity: 0 GB
Intel® Optane™ Memory module installed: No
SSD interface: PCI Express
Total SSDs capacity: 2 TB
SSD capacity: 2 TB
NVMe: Yes
SSD form factor: M.2
HDD capacity: 0 GB
Number of SSDs installed: 1
Number of storage drives supported: 6
Number of storage drives installed: 1
Card reader integrated: No
M.2 SSD size: 2280 (22 x 80 mm)
Ports & interfaces
Combo headphone/mic port: Yes
DisplayPorts quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Number of SATA III connectors: 4
S/PDIF out port: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DC-in jack: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Line-out: Yes
Line-in: Yes
Number of rear USB ports: 8
Number of rear audio ports: 5
Intel® Thunderbolt 4: No
Microphone in: Yes
Number of front USB ports: 3
HDMI ports quantity: 2
DVI port: No
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Number of front audio ports: 1
Intel® Thunderbolt 5: No
Headphone outputs: 1
Fiber NIC port (Flex I/O): No
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
Safety warning
Warnings: Do not open the computer case without disconnecting it from the power source., Avoid contact with water or other liquids., If the battery is damaged or spilled, avoid contact with the material and contact service immediately.
