Processor
Processor base power: 120 W
Number of processors installed: 1
Processor manufacturer: AMD
Processor cache type: L3
Processor socket: Socket AM5
Processor generation: AMD Ryzen 7000 Series
Processor cores: 8
Processor boost frequency: 5 GHz
Processor threads: 16
Processor model: 7800X3D
Processor frequency: 4.2 GHz
Processor family: AMD Ryzen™ 7
Processor cache: 96 MB
Graphics
Number of discrete graphics cards: 1
Graphics card DisplayPorts quantity: 3
AMD FreeSync: Yes
On-board graphics card family: AMD Radeon Graphics
Discrete graphics memory type: GDDR7
On-board GPU manufacturer: AMD
Graphics card HDMI ports quantity: 1
On-board graphics card: Yes
Discrete graphics card: Yes
On-board graphics card cores: 2
Discrete GPU manufacturer: NVIDIA
On-board graphics card model: AMD Radeon Graphics
Discrete graphics card memory: 32 GB
Discrete graphics card model: NVIDIA GeForce RTX 5090
NVIDIA GameWorks VR: Yes
CUDA: Yes
NVIDIA G-SYNC: Yes
Memory
Memory layout (slots x size): 2 x 16 GB
Internal memory manufacturer: Kingston
Memory slots: 4x DIMM
Memory channels: Dual-channel
Internal memory type: DDR5-SDRAM
Internal memory: 32 GB
Maximum internal memory: 192 GB
Memory clock speed: 6000 MHz
Non-ECC: Yes
Design
Viewing window: Yes
Water cooling system: Yes
Number of 2.5" bays: 4
Refurbished: No
Number of 3.5" bays: 4
Chassis type: Midi Tower
VESA mounting: No
Housing material: Metal, Plastic, Tempered glass
Product colour: Black
RGB backlighting: Yes
Power
Power supply: 850 W
80 PLUS certification: 80 PLUS Gold
Power supply input voltage: 100-240 V
Weight & dimensions
Width: 285 mm
Height: 446 mm
Depth: 450 mm
Weight: 15 kg
Network
Bluetooth version: 5.2
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi standards: 802.11g, 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
Bluetooth: Yes
Ethernet LAN data rates: 2500 Mbit/s, 1000, 100, 10
Antenna type: 2x2
Internal components: ASUS TUF Gaming B650M-PLUS WIFI / NVIDIA GeForce RTX 5090 / Kingston Fury Beast RGB / WD Black SN850X / ASUS TUF Gaming LC II 360 ARGB/ ASUS TUF Gaming TF120 ARGB / ASUS TUF Gaming 850W / ASUS TUF Gaming GT502
Performance
Powered by: ASUS
Product type: PC
Virtual Reality (VR) ready: Yes
Market positioning: Gaming
Motherboard chipset: AMD B650
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Packaging content
Keyboard included: No
Display included: No
Mouse included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 4.x) slots: 1
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
SSD capacity: 2 TB
Number of storage drives installed: 1
Total SSDs capacity: 2 TB
SSD form factor: M.2
M.2 SSD size: 2280 (22 x 80 mm)
NVMe: Yes
Intel® Optane™ Memory module installed: No
SSD interface: PCI Express
HDD capacity: 0 GB
Storage media: SSD
Card reader integrated: No
Total HDDs capacity: 0 GB
Number of SSDs installed: 1
Number of storage drives supported: 6
Total storage capacity: 2 TB
Optical drive type: No
Ports & interfaces
Line-in: Yes
Fiber NIC port (Flex I/O): No
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Number of front USB ports: 3
Headphone outputs: 1
Number of rear USB ports: 8
Microphone in: Yes
HDMI ports quantity: 2
Line-out: Yes
USB 3.2 Gen 2x2 Type-C ports quantity: 1
DVI port: No
Intel® Thunderbolt 4: No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
S/PDIF out port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Intel® Thunderbolt 5: No
Combo headphone/mic port: Yes
Number of SATA III connectors: 4
Number of front audio ports: 1
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 4
DC-in jack: No
Number of rear audio ports: 5
Special features: The specification and description are for illustrative purposes only.
Other features
Built-in microphone: No
TV tuner integrated: No
Safety warning
Warnings: If the battery is damaged or spilled, avoid contact with the material and contact service immediately., Do not open the computer case without disconnecting it from the power source., Avoid contact with water or other liquids.
