Processor
Processor generation: AMD Ryzen 9000 Series
Number of processors installed: 1
Processor manufacturer: AMD
Processor base power: 120 W
Processor socket: Socket AM5
Processor model: 9800X3D
Processor family: AMD Ryzen™ 7
Processor cache: 96 MB
Processor boost frequency: 5.2 GHz
Processor cores: 8
Processor cache type: L3
Processor frequency: 4.7 GHz
Processor threads: 16
Graphics
On-board graphics card: Yes
Number of discrete graphics cards: 1
Discrete GPU manufacturer: NVIDIA
On-board graphics card family: AMD Radeon Graphics
Discrete graphics memory type: GDDR7
Discrete graphics card model: NVIDIA GeForce RTX 5090
Graphics card HDMI ports quantity: 1
AMD FreeSync: Yes
On-board GPU manufacturer: AMD
Graphics card DisplayPorts quantity: 3
CUDA: Yes
Discrete graphics card: Yes
On-board graphics card cores: 2
On-board graphics card model: AMD Radeon Graphics
Discrete graphics card memory: 32 GB
NVIDIA GameWorks VR: Yes
NVIDIA G-SYNC: Yes
Memory
Memory layout (slots x size): 2 x 16 GB
Internal memory manufacturer: Kingston
Maximum internal memory: 192 GB
Memory slots: 4x DIMM
Non-ECC: Yes
Memory clock speed: 6000 MHz
Memory channels: Dual-channel
Internal memory type: DDR5-SDRAM
Internal memory: 32 GB
Design
Chassis type: Midi Tower
Viewing window: Yes
Water cooling system: Yes
VESA mounting: No
Number of 3.5" bays: 4
Number of 2.5" bays: 4
Housing material: Metal, Plastic, Tempered glass
Refurbished: No
Product colour: Black
RGB backlighting: Yes
Power
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Gold
Power supply: 1000 W
Weight & dimensions
Depth: 450 mm
Width: 285 mm
Height: 446 mm
Weight: 15 kg
Network
Ethernet LAN data rates: 100, 1000, 2500 Mbit/s, 10
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi: Yes
Antenna type: 2x2
Bluetooth version: 5.2
Bluetooth: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Internal components: ASUS TUF Gaming B650M-PLUS WIFI / NVIDIA GeForce RTX 5090 / Kingston Fury Beast RGB / WD Black SN850X / ASUS TUF Gaming LC II 360 ARGB/ ASUS TUF Gaming TF120 ARGB / ASUS TUF Gaming 1000W / ASUS TUF Gaming GT502
Performance
Market positioning: Gaming
Powered by: ASUS
Audio output channels: 7.1 channels
Product type: PC
Motherboard chipset: AMD B650
Virtual Reality (VR) ready: Yes
Motherboard form factor: micro ATX
Packaging content
Display included: No
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 4.x) slots: 1
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Total HDDs capacity: 0 GB
Number of storage drives installed: 1
Total SSDs capacity: 2 TB
Number of storage drives supported: 6
NVMe: Yes
M.2 SSD size: 2280 (22 x 80 mm)
SSD capacity: 2 TB
Card reader integrated: No
SSD form factor: M.2
Intel® Optane™ Memory module installed: No
SSD interface: PCI Express
HDD capacity: 0 GB
Number of SSDs installed: 1
Optical drive type: No
Total storage capacity: 2 TB
Storage media: SSD
Ports & interfaces
Microphone in: Yes
Fiber NIC port (Flex I/O): No
Number of front USB ports: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Headphone outputs: 1
Number of rear USB ports: 8
Line-in: Yes
Line-out: Yes
Intel® Thunderbolt 4: No
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Number of front audio ports: 1
Number of rear audio ports: 5
S/PDIF out port: Yes
DC-in jack: No
Number of SATA III connectors: 4
DVI port: No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DisplayPorts quantity: 4
Intel® Thunderbolt 5: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Combo headphone/mic port: Yes
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 2
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
Safety warning
Warnings: Avoid contact with water or other liquids., If the battery is damaged or spilled, avoid contact with the material and contact service immediately., Do not open the computer case without disconnecting it from the power source.
