Processor
Processor cache type: L3
Processor family: AMD Ryzen™ 7
Processor frequency: 4.1 GHz
Processor manufacturer: AMD
Processor model: 8700F
Processor cores: 8
Processor cache: 16 MB
Processor threads: 16
Processor socket: Socket AM5
Processor generation: AMD Ryzen 8000 Series
Processor base power: 65 W
Number of processors installed: 1
Processor boost frequency: 5 GHz
Graphics
NVIDIA GameWorks VR: No
On-board graphics card: No
NVIDIA G-SYNC: No
On-board graphics card model: Not available
Discrete graphics card memory: 16 GB
Discrete graphics card: Yes
Discrete graphics memory type: GDDR7
Number of discrete graphics cards: 1
Discrete GPU manufacturer: NVIDIA
Graphics card HDMI ports quantity: 1
AMD FreeSync: Yes
Graphics card DisplayPorts quantity: 3
Discrete graphics card model: NVIDIA GeForce RTX 5070 Ti
CUDA: No
Memory
Memory channels: Dual-channel
Internal memory type: DDR5-SDRAM
ECC: No
Internal memory: 32 GB
Memory clock speed: 6000 MHz
Memory layout (slots x size): 2 x 16 GB
Internal memory manufacturer: Kingston
Memory slots: 4x DIMM
Maximum internal memory: 128 GB
Design
Number of 2.5" bays: 2
Number of 3.5" bays: 2
Housing material: Metal, Plastic, Tempered glass
Chassis type: Midi Tower
Viewing window: Yes
Water cooling system: No
Refurbished: No
RGB backlighting: Yes
Product colour: Black
Power
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Gold
Power supply: 850 W
Weight & dimensions
Depth: 460 mm
Width: 240 mm
Weight: 10 kg
Height: 506 mm
Network
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Bluetooth version: 5.2
Ethernet LAN data rates: 100, 10, 1000, 2500 Mbit/s
Antenna type: 2x2
Bluetooth: Yes
Internal components: ASUS TUF GAMING B650-PLUS WIFI / NVIDIA GeForce RTX 5070 Ti / Kingston Fury Beast RGB / WD Black SN770 / ENDORFY Fera 5 ARGB / Corsair RM850x / Corsair 3500X ARGB
Performance
Market positioning: Gaming
Powered by: CORSAIR ICUE
Virtual Reality (VR) ready: Yes
Product type: PC
Motherboard chipset: AMD B650
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Packaging content
Display included: No
Keyboard included: No
Mouse included: No
Expansion slots
PCI Express x1 (Gen 4.x) slots: 2
PCI Express x16 (Gen 4.x) slots: 2
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Optical drive type: No
Card reader integrated: No
Total storage capacity: 2 TB
Storage media: SSD
Number of storage drives supported: 7
M.2 SSD size: 2280 (22 x 80 mm)
SSD form factor: M.2
NVMe: Yes
SSD capacity: 2 TB
Number of SSDs installed: 1
Number of storage drives installed: 1
Total SSDs capacity: 2 TB
Intel® Optane™ Memory module installed: No
SSD interface: PCI Express
Ports & interfaces
Number of SATA III connectors: 4
Ethernet LAN (RJ-45) ports: 1
Combo headphone/mic port: Yes
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
Microphone in: Yes
HDMI ports quantity: 1
DVI port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Fiber NIC port (Flex I/O): No
Intel® Thunderbolt 4: No
Number of front USB ports: 3
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Headphone outputs: 1
Line-out: Yes
Line-in: Yes
S/PDIF out port: No
Number of rear audio ports: 5
DisplayPorts quantity: 3
Intel® Thunderbolt 5: No
Number of front audio ports: 1
DC-in jack: No
Number of rear USB ports: 8
Special features: The specification and description are for illustrative purposes only.
Other features
Built-in microphone: No
TV tuner integrated: No
