Processor
Processor model: 7700
Processor cache type: L3
Processor cache: 32 MB
Processor cores: 8
Processor frequency: 3.8 GHz
Processor family: AMD Ryzen™ 7
Processor boost frequency: 5.3 GHz
Processor threads: 16
Number of processors installed: 1
Processor manufacturer: AMD
Processor generation: AMD Ryzen 7000 Series
Processor socket: Socket AM5
Processor base power: 65 W
Graphics
Discrete graphics card memory: 12 GB
NVIDIA GameWorks VR: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5070
On-board graphics card model: AMD Radeon Graphics
CUDA: Yes
NVIDIA G-SYNC: Yes
Number of discrete graphics cards: 1
On-board graphics card family: AMD Radeon Graphics
Graphics card HDMI ports quantity: 1
Discrete GPU manufacturer: NVIDIA
Graphics card DisplayPorts quantity: 3
Discrete graphics card: Yes
On-board GPU manufacturer: AMD
On-board graphics card: Yes
Discrete graphics memory type: GDDR7
Memory
Memory clock speed: 6000 MHz
Memory channels: Dual-channel
Internal memory: 32 GB
Maximum internal memory: 192 GB
Internal memory type: DDR5-SDRAM
Non-ECC: Yes
Memory layout (slots x size): 2 x 16 GB
Internal memory manufacturer: Kingston
Memory slots: 4x DIMM
Design
Product colour: Black
Housing material: Metal, Plastic, Tempered glass
Number of 3.5" bays: 1
Refurbished: No
Chassis type: Midi Tower
VESA mounting: No
Viewing window: Yes
Number of 2.5" bays: 6
Water cooling system: No
RGB backlighting: Yes
Power
80 PLUS certification: 80 PLUS Gold
Power supply: 750 W
Power supply input voltage: 100-240 V
Weight & dimensions
Weight: 10 kg
Width: 228 mm
Height: 486 mm
Depth: 429 mm
Network
Ethernet LAN data rates: 10, 100, 1000, 2500 Mbit/s
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax)
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Antenna type: 2x2
Wi-Fi: Yes
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN: Yes
Bluetooth version: 5.2
Internal components: ASUS TUF Gaming B650M-PLUS WIFI / NVIDIA GeForce RTX 5070 / Kingston Fury Beast RGB / WD Black SN770 / ENDORFY Fera 5 Black ARGB / Gigabyte UD750GM PG5 / ENDORFY Arx 500 ARGB
Performance
Audio output channels: 7.1 channels
Motherboard chipset: AMD B650
Motherboard form factor: micro ATX
Market positioning: Gaming
Powered by: ENDORFY
Product type: PC
Virtual Reality (VR) ready: Yes
Packaging content
Display included: No
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 4.x) slots: 1
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Total storage capacity: 2 TB
Storage media: SSD
Optical drive type: No
SSD capacity: 2 TB
Number of storage drives installed: 1
Card reader integrated: No
Number of storage drives supported: 6
SSD interface: PCI Express
Intel® Optane™ Memory module installed: No
NVMe: Yes
SSD form factor: M.2
Total SSDs capacity: 2 TB
Number of SSDs installed: 1
M.2 SSD size: 2280 (22 x 80 mm)
Ports & interfaces
DVI port: No
Combo headphone/mic port: No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
S/PDIF out port: No
Number of SATA III connectors: 4
DisplayPorts quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
HDMI ports quantity: 2
DC-in jack: No
Headphone outputs: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Microphone in: Yes
Number of front USB ports: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Intel® Thunderbolt 4: No
Line-in: Yes
Line-out: Yes
Fiber NIC port (Flex I/O): No
Number of rear audio ports: 5
Number of rear USB ports: 8
Number of front audio ports: 2
Intel® Thunderbolt 5: No
Special features: The specification and description are for illustrative purposes only.
Other features
Built-in microphone: No
TV tuner integrated: No
