Processor
Number of processors installed: 1
Processor manufacturer: AMD
Processor cache type: L3
Processor socket: Socket AM5
Processor base power: 120 W
Processor generation: AMD Ryzen 9000 Series
Processor boost frequency: 5.2 GHz
Processor threads: 16
Processor cores: 8
Processor family: AMD Ryzen™ 7
Processor cache: 96 MB
Processor model: 9800X3D
Processor frequency: 4.7 GHz
Graphics
Graphics card DisplayPorts quantity: 3
On-board GPU manufacturer: AMD
Discrete GPU manufacturer: NVIDIA
Graphics card HDMI ports quantity: 1
On-board graphics card: Yes
On-board graphics card family: AMD Radeon Graphics
AMD FreeSync: Yes
Number of discrete graphics cards: 1
Discrete graphics card: Yes
Discrete graphics memory type: GDDR7
NVIDIA G-SYNC: Yes
CUDA: Yes
NVIDIA GameWorks VR: Yes
On-board graphics card model: AMD Radeon Graphics
Discrete graphics card memory: 12 GB
Discrete graphics card model: NVIDIA GeForce RTX 5070
Memory
Internal memory manufacturer: Kingston
ECC: No
Memory channels: Dual-channel
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Memory clock speed: 6000 MHz
Maximum internal memory: 192 GB
Design
Refurbished: No
Viewing window: Yes
Water cooling system: Yes
Number of 3.5" bays: 1
Housing material: Metal, Plastic, Tempered glass
VESA mounting: No
Chassis type: Midi Tower
Number of 2.5" bays: 6
Product colour: Black
RGB backlighting: Yes
Power
80 PLUS certification: 80 PLUS Gold
Power supply: 750 W
Power supply input voltage: 100-240 V
Weight & dimensions
Height: 486 mm
Width: 228 mm
Depth: 429 mm
Weight: 10 kg
Network
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n)
Cabling technology: 10/100/1000Base-T(X)
Bluetooth version: 5.2
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
Ethernet LAN: Yes
Antenna type: 2x2
Bluetooth: Yes
Ethernet LAN data rates: 10, 100, 1000, 2500 Mbit/s
Internal components: ASUS TUF Gaming B650M-PLUS WIFI / NVIDIA GeForce RTX 5070 / Kingston Fury Beast RGB / WD Black SN770 / ENDORFY Navis F240 ARGB / Gigabyte UD750GM PG5 / ENDORFY Arx 500 ARGB
Performance
Powered by: ENDORFY
Virtual Reality (VR) ready: Yes
Market positioning: Gaming
Product type: PC
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset: AMD B650
Packaging content
Display included: No
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 4.x) slots: 1
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
M.2 SSD size: 2280 (22 x 80 mm)
Number of storage drives supported: 6
Card reader integrated: No
NVMe: Yes
Number of storage drives installed: 1
Intel® Optane™ Memory module installed: No
Storage media: SSD
SSD form factor: M.2
SSD capacity: 2 TB
SSD interface: PCI Express
Total SSDs capacity: 2 TB
Number of SSDs installed: 1
Optical drive type: No
Total storage capacity: 2 TB
Ports & interfaces
Fiber NIC port (Flex I/O): No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Line-out: Yes
HDMI ports quantity: 2
Line-in: Yes
Microphone in: Yes
Number of front audio ports: 2
Headphone outputs: 1
Number of rear USB ports: 8
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
DVI port: No
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Number of front USB ports: 3
Intel® Thunderbolt 4: No
DC-in jack: No
S/PDIF out port: No
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Combo headphone/mic port: No
DisplayPorts quantity: 4
Number of rear audio ports: 5
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
Intel® Thunderbolt 5: No
