Processor
Processor cores: 8
Processor manufacturer: AMD
Processor cache: 32 MB
Processor frequency: 4.5 GHz
Processor threads: 16
Processor cache type: L3
Processor model: 7700X
Processor socket: Socket AM5
Number of processors installed: 1
Processor base power: 105 W
Processor generation: AMD Ryzen 7000 Series
Processor family: AMD Ryzen™ 7
Processor boost frequency: 5.4 GHz
Graphics
Discrete graphics card memory: 16 GB
On-board graphics card: Yes
Discrete GPU manufacturer: NVIDIA
Discrete graphics card: Yes
On-board graphics card family: AMD Radeon Graphics
Discrete graphics memory type: GDDR7
On-board GPU manufacturer: AMD
Number of discrete graphics cards: 1
Graphics card DisplayPorts quantity: 3
Graphics card HDMI ports quantity: 1
NVIDIA GameWorks VR: Yes
CUDA: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5070 Ti
On-board graphics card model: AMD Radeon Graphics
NVIDIA G-SYNC: Yes
Memory
Internal memory type: DDR5-SDRAM
Memory channels: Dual-channel
Memory clock speed: 6000 MHz
Internal memory: 32 GB
Internal memory manufacturer: Kingston
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Non-ECC: Yes
Maximum internal memory: 192 GB
Design
Viewing window: Yes
Refurbished: No
Water cooling system: Yes
VESA mounting: No
Chassis type: Midi Tower
Number of 3.5" bays: 1
Number of 2.5" bays: 6
Housing material: Metal, Plastic, Tempered glass
RGB backlighting: Yes
Product colour: Black
Power
Power supply input voltage: 100-240 V
Power supply: 850 W
80 PLUS certification: 80 PLUS Gold
Weight & dimensions
Width: 228 mm
Depth: 489 mm
Height: 486 mm
Weight: 10 kg
Network
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 4 (802.11n)
Cabling technology: 10/100/1000Base-T(X)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
Ethernet LAN: Yes
Bluetooth version: 5.2
Ethernet LAN data rates: 1000, 2500 Mbit/s, 10, 100
Bluetooth: Yes
Antenna type: 2x2
Internal components: ASUS TUF Gaming B650M-PLUS WIFI / NVIDIA GeForce RTX 5070 Ti / Kingston Fury Beast RGB / WD Black SN770 / ENDORFY Navis F240 ARGB / Corsair RM850e / ENDORFY Arx 700 ARGB
Performance
Powered by: ENDORFY
Market positioning: Gaming
Product type: PC
Virtual Reality (VR) ready: Yes
Motherboard form factor: micro ATX
Motherboard chipset: AMD B650
Audio output channels: 7.1 channels
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 4.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Storage media: SSD
Total storage capacity: 2 TB
Card reader integrated: No
Number of storage drives supported: 6
SSD interface: PCI Express
SSD capacity: 2 TB
Number of storage drives installed: 1
SSD form factor: M.2
NVMe: Yes
M.2 SSD size: 2280 (22 x 80 mm)
Intel® Optane™ Memory module installed: No
Total SSDs capacity: 2 TB
Number of SSDs installed: 1
Optical drive type: No
Ports & interfaces
Combo headphone/mic port: No
Microphone in: Yes
DVI port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 2
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Headphone outputs: 1
Number of front USB ports: 3
Fiber NIC port (Flex I/O): No
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Intel® Thunderbolt 4: No
Line-out: Yes
Line-in: Yes
DisplayPorts quantity: 4
S/PDIF out port: No
Number of rear USB ports: 8
Number of rear audio ports: 5
Number of front audio ports: 2
Number of SATA III connectors: 4
DC-in jack: No
Intel® Thunderbolt 5: No
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
