Processor
Processor frequency: 4.2 GHz
Processor threads: 16
Processor boost frequency: 5 GHz
Processor family: AMD Ryzen™ 7
Processor cache: 96 MB
Processor cache type: L3
Processor cores: 8
Processor model: 7800X3D
Processor socket: Socket AM5
Processor manufacturer: AMD
Processor base power: 120 W
Processor generation: AMD Ryzen 7000 Series
Number of processors installed: 1
Graphics
Graphics card Open GL support: Yes
CUDA: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5070 Ti
NVIDIA G-SYNC: Yes
NVIDIA GameWorks VR: Yes
Discrete graphics card memory: 16 GB
On-board graphics card model: AMD Radeon Graphics
AMD FreeSync: Yes
On-board graphics card family: AMD Radeon Graphics
On-board GPU manufacturer: AMD
Graphics card DisplayPorts quantity: 3
Discrete graphics memory type: GDDR7
Graphics card HDMI ports quantity: 1
Discrete graphics card: Yes
Number of discrete graphics cards: 1
On-board graphics card: Yes
Discrete GPU manufacturer: NVIDIA
Memory
ECC: No
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Memory clock speed: 6000 MHz
Memory slots: 4x DIMM
Memory layout (slots x size): 2 x 16 GB
Design
RGB backlighting: Yes
Product colour: Black
Water cooling system: Yes
Chassis type: Midi Tower
Number of 2.5" bays: 5
VESA mounting: No
Viewing window: Yes
Refurbished: No
Number of 3.5" bays: 2
Housing material: Metal, Plastic, Tempered glass
Power
Power supply: 750 W
80 PLUS certification: 80 PLUS Gold
Power supply input voltage: 100-240 V
Weight & dimensions
Weight: 10 kg
Depth: 440 mm
Height: 500 mm
Width: 230 mm
Network
Antenna type: 2x2
Ethernet LAN data rates: 2500 Mbit/s, 10, 1000 Mbit/s, 100
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11b, 802.11g, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac)
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.3
Wi-Fi: Yes
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Internal components: ASUS TUF GAMING B650E-E WIFI / NVIDIA GeForce RTX 5070 Ti / WD Blue SN5000 / Phanteks XT View Window
Performance
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Motherboard chipset: AMD B650
Powered by: VIEW
Product type: PC
Market positioning: Gaming
Virtual Reality (VR) ready: Yes
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 4.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system architecture: 64-bit
Operating system installed: Windows 11 Home
Storage
Storage media: SSD
Optical drive type: No
Total storage capacity: 1 TB
M.2 SSD size: 2280 (22 x 80 mm)
NVMe: Yes
SSD interface: PCI Express
Number of storage drives supported: 7
Total SSDs capacity: 1 TB
Card reader integrated: No
Number of storage drives installed: 1
SSD capacity: 1 TB
Intel® Optane™ Memory module installed: No
Number of SSDs installed: 1
SSD form factor: M.2
Ports & interfaces
Number of rear audio ports: 3
Number of front audio ports: 1
Intel® Thunderbolt 5: No
Number of rear USB ports: 8
DC-in jack: No
Number of SATA III connectors: 4
DisplayPorts quantity: 4
S/PDIF out port: No
HDMI ports quantity: 2
Combo headphone/mic port: Yes
USB 2.0 ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DVI port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Microphone in: Yes
Number of front USB ports: 2
Fiber NIC port (Flex I/O): No
Intel® Thunderbolt 4: No
Headphone outputs: 1
Line-in: Yes
Line-out: Yes
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
