Processor
Processor family: AMD Ryzen™ 9
Processor boost frequency: 5.5 GHz
Processor model: 9900X3D
Processor threads: 24
Number of processors installed: 1
Processor cache type: L3
Processor cache: 128 MB
Processor base power: 120 W
Processor cores: 12
Processor manufacturer: AMD
Processor frequency: 4.4 GHz
Processor socket: Socket AM5
Processor generation: AMD Ryzen 9000 Series
Graphics
Number of discrete graphics cards: 1
AMD FreeSync: Yes
NVIDIA GameWorks VR: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5090
Discrete GPU manufacturer: NVIDIA
CUDA: Yes
Discrete graphics memory type: GDDR7
On-board graphics card model: AMD Radeon Graphics
Discrete graphics card memory: 32 GB
On-board graphics card family: AMD Radeon Graphics
NVIDIA G-SYNC: Yes
Graphics card Open GL support: Yes
On-board graphics card: Yes
On-board GPU manufacturer: AMD
Graphics card HDMI ports quantity: 1
Graphics card DisplayPorts quantity: 3
Discrete graphics card: Yes
Memory
Internal memory type: DDR5-SDRAM
Memory channels: Dual-channel
ECC: No
Internal memory manufacturer: Kingston
Internal memory: 32 GB
Memory slots: 4x DIMM
Memory layout (slots x size): 2 x 16 GB
Memory clock speed: 6000 MHz
Maximum internal memory: 192 GB
Design
Water cooling system: Yes
Number of 3.5" bays: 2
Product colour: Black
Viewing window: Yes
Number of 2.5" bays: 5
Chassis type: Midi Tower
RGB backlighting: Yes
VESA mounting: No
Housing material: Metal, Plastic, Tempered glass
Refurbished: No
Power
80 PLUS certification: 80 PLUS Gold
Power supply input voltage: 100-240 V
Power supply: 1000 W
Weight & dimensions
Height: 500 mm
Depth: 440 mm
Width: 230 mm
Weight: 10 kg
Network
Ethernet LAN data rates: 1000, 10, 2500 Mbit/s, 100
Antenna type: 2x2
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n)
Cabling technology: 10/100/1000Base-T(X)
Bluetooth version: 5.2
Wi-Fi: Yes
Bluetooth: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Internal components: ASUS TUF GAMING B650M-PLUS WIFI / NVIDIA GeForce RTX 5090 / Kingston Fury Beast RGB / WD Black SN770 / ENDORFY Navis F360 ARGB / Corsair RM1000x / Phanteks XT View Window
Performance
Motherboard form factor: micro ATX
Motherboard chipset: AMD B650
Audio output channels: 7.1 channels
Product type: PC
Powered by: VIEW
Market positioning: Gaming
Virtual Reality (VR) ready: Yes
Packaging content
Keyboard included: No
Mouse included: No
Expansion slots
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 2
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Optical drive type: No
Card reader integrated: No
SSD form factor: M.2
Number of storage drives supported: 6
Intel® Optane™ Memory module installed: No
Total SSDs capacity: 2 TB
SSD interface: PCI Express
Number of storage drives installed: 1
SSD capacity: 2 TB
NVMe: Yes
Number of SSDs installed: 1
Storage media: SSD
M.2 SSD size: 2280 (22 x 80 mm)
Total storage capacity: 2 TB
Ports & interfaces
HDMI ports quantity: 2
DisplayPorts quantity: 4
Headphone outputs: 1
Intel® Thunderbolt 4: No
Combo headphone/mic port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
DC-in jack: No
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Number of rear audio ports: 6
Number of SATA III connectors: 4
S/PDIF out port: No
DVI port: No
Number of rear USB ports: 8
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Fiber NIC port (Flex I/O): No
Line-out: Yes
Number of front USB ports: 2
Intel® Thunderbolt 5: No
Number of front audio ports: 1
Line-in: Yes
Microphone in: Yes
USB 2.0 ports quantity: 4
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
