Processor
Processor cache: 96 MB
Number of processors installed: 1
Processor cache type: L3
Processor model: 7600X3D
Processor threads: 12
Processor socket: Socket AM5
Processor manufacturer: AMD
Processor base power: 65 W
Processor generation: AMD Ryzen 7000 Series
Processor frequency: 4.1 GHz
Processor family: AMD Ryzen™ 5
Processor cores: 6
Processor boost frequency: 4.7 GHz
Graphics
On-board graphics card: Yes
Discrete GPU manufacturer: AMD
Graphics card DisplayPorts quantity: 3
On-board graphics card family: AMD Radeon Graphics
Discrete graphics card: Yes
Discrete graphics card memory: 16 GB
On-board GPU manufacturer: AMD
Graphics card HDMI ports quantity: 1
Discrete graphics memory type: GDDR6
AMD FreeSync: Yes
Number of discrete graphics cards: 1
Graphics card Open GL support: Yes
On-board graphics card model: AMD Radeon Graphics
NVIDIA G-SYNC: No
NVIDIA GameWorks VR: No
Discrete graphics card model: AMD Radeon RX 9070
CUDA: No
Memory
ECC: No
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Memory clock speed: 6000 MHz
Memory channels: Dual-channel
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Maximum internal memory: 192 GB
Design
VESA mounting: No
Water cooling system: No
Refurbished: No
Chassis type: Midi Tower
Viewing window: Yes
Number of 2.5" bays: 5
Housing material: Metal, Plastic, Tempered glass
Number of 3.5" bays: 2
Product colour: Black
RGB backlighting: Yes
Power
Power supply: 750 W
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Bronze
Weight & dimensions
Width: 230 mm
Height: 500 mm
Depth: 440 mm
Weight: 10 kg
Network
Wi-Fi: Yes
Bluetooth version: 5.2
Wi-Fi standards: 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11b
Cabling technology: 10/100/1000Base-T(X)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Ethernet LAN data rates: 10, 2500 Mbit/s, 100, 1000
Bluetooth: Yes
Antenna type: 2x2
Internal components: ASUS TUF GAMING B650M-PLUS WIFI / AMD Radeon RX 9070 / WD Blue SN580 / Phanteks XT View Window
Performance
Powered by: VIEW
Product type: PC
Market positioning: Gaming
Virtual Reality (VR) ready: Yes
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset: AMD B650
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 3.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
SSD capacity: 1 TB
SSD interface: PCI Express
Total SSDs capacity: 1 TB
Number of storage drives installed: 1
Number of storage drives supported: 6
SSD form factor: M.2
NVMe: Yes
Intel® Optane™ Memory module installed: No
Storage media: SSD
Card reader integrated: No
Total storage capacity: 1 TB
Number of SSDs installed: 1
M.2 SSD size: 2280 (22 x 80 mm)
Optical drive type: No
Ports & interfaces
HDMI ports quantity: 2
Headphone outputs: 1
Combo headphone/mic port: Yes
Number of front USB ports: 2
Line-in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Fiber NIC port (Flex I/O): No
Line-out: Yes
DVI port: No
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Intel® Thunderbolt 4: No
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Number of SATA III connectors: 4
Number of front audio ports: 1
DisplayPorts quantity: 4
Number of rear USB ports: 8
Intel® Thunderbolt 5: No
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
S/PDIF out port: No
DC-in jack: No
Number of rear audio ports: 6
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
