Processor
Processor generation: AMD Ryzen 7000 Series
Processor base power: 65 W
Number of processors installed: 1
Processor socket: Socket AM5
Processor boost frequency: 5.3 GHz
Processor threads: 16
Processor family: AMD Ryzen™ 7
Processor frequency: 3.8 GHz
Processor cores: 8
Processor model: 7700
Processor manufacturer: AMD
Processor cache type: L3
Processor cache: 32 MB
Graphics
On-board GPU manufacturer: AMD
Discrete graphics card: Yes
On-board graphics card family: AMD Radeon Graphics
AMD FreeSync: Yes
Graphics card DisplayPorts quantity: 3
Discrete GPU manufacturer: AMD
Graphics card HDMI ports quantity: 1
Discrete graphics memory type: GDDR6
Number of discrete graphics cards: 1
Discrete graphics card memory: 16 GB
Discrete graphics card model: AMD Radeon RX 9070
NVIDIA GameWorks VR: No
On-board graphics card model: AMD Radeon Graphics
On-board graphics card: Yes
NVIDIA G-SYNC: No
CUDA: No
Memory
Memory slots: 4x DIMM
Memory layout (slots x size): 2 x 16 GB
Internal memory type: DDR5-SDRAM
Maximum internal memory: 192 GB
ECC: No
Memory channels: Dual-channel
Internal memory: 32 GB
Memory clock speed: 6000 MHz
Design
Viewing window: Yes
Refurbished: No
VESA mounting: No
Water cooling system: No
Chassis type: Midi Tower
Housing material: Metal, Plastic, Tempered glass
Number of 2.5" bays: 3
Number of 3.5" bays: 2
Product colour: Black
RGB backlighting: Yes
Power
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Bronze
Power supply: 750 W
Weight & dimensions
Height: 500 mm
Depth: 440 mm
Width: 230 mm
Weight: 10 kg
Network
Cabling technology: 10/100/1000Base-T(X)
Bluetooth version: 5.2
Ethernet LAN: Yes
Wi-Fi: Yes
Antenna type: 2x2
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 5 (802.11ac)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet LAN data rates: 1000, 10, 100, 2500 Mbit/s
Bluetooth: Yes
Internal components: ASUS TUF GAMING B650M-PLUS WIFI / AMD Radeon RX 9070 / WD Blue SN580 / Phanteks XT View
Performance
Virtual Reality (VR) ready: Yes
Product type: PC
Powered by: VIEW
Market positioning: Gaming
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset: AMD B650
Expansion slots
PCI Express x1 (Gen 4.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 2
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system architecture: 64-bit
Operating system installed: Windows 11 Home
Storage
SSD capacity: 1 TB
NVMe: Yes
Number of storage drives installed: 1
SSD interface: PCI Express
Intel® Optane™ Memory module installed: No
Total SSDs capacity: 1 TB
Number of SSDs installed: 1
SSD form factor: M.2
Card reader integrated: No
Storage media: SSD
Optical drive type: No
Number of storage drives supported: 6
Total storage capacity: 1 TB
Ports & interfaces
Intel® Thunderbolt 4: No
Number of front USB ports: 2
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Line-out: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Number of rear audio ports: 5
Number of front audio ports: 1
Microphone in: Yes
Line-in: Yes
Headphone outputs: 1
Number of rear USB ports: 8
HDMI ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 4
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Number of SATA III connectors: 4
Combo headphone/mic port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
S/PDIF out port: No
DVI port: No
DC-in jack: No
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
