Processor
Processor generation: AMD Ryzen 8000 Series
Processor base power: 65 W
Number of processors installed: 1
Processor socket: Socket AM5
Processor manufacturer: AMD
Processor cores: 8
Processor cache type: L3
Processor model: 8700F
Processor cache: 16 MB
Processor threads: 16
Processor boost frequency: 5 GHz
Processor family: AMD Ryzen™ 7
Processor frequency: 4.1 GHz
Graphics
Discrete GPU manufacturer: NVIDIA
On-board graphics card: No
Discrete graphics card: Yes
Graphics card DisplayPorts quantity: 3
Graphics card HDMI ports quantity: 1
Discrete graphics memory type: GDDR7
Number of discrete graphics cards: 1
Discrete graphics card memory: 8 GB
Discrete graphics card model: NVIDIA GeForce RTX 5060
CUDA: Yes
NVIDIA G-SYNC: Yes
NVIDIA GameWorks VR: Yes
Memory
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Memory clock speed: 6000 MHz
Internal memory type: DDR5-SDRAM
Maximum internal memory: 256 GB
Non-ECC: Yes
Internal memory: 32 GB
Memory channels: Dual-channel
Design
Water cooling system: No
Refurbished: No
Viewing window: Yes
Number of 2.5" bays: 3
Housing material: Metal, Plastic, Tempered glass
Chassis type: Midi Tower
RGB backlighting: Yes
VESA mounting: No
Number of 3.5" bays: 2
Product colour: Black
Power
Power supply: 650 W
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Gold
Weight & dimensions
Width: 230 mm
Depth: 440 mm
Height: 500 mm
Weight: 10 kg
Network
Wi-Fi standards: 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11b
Bluetooth version: 5.3
Wi-Fi: Yes
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN: Yes
Antenna type: 2x2
Ethernet LAN data rates: 100, 1000, 10
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Internal components: Gigabyte B650 EAGLE AX / NVIDIA GeForce RTX 5060 / WD Blue SN5000 / Phanteks XT View
Performance
Powered by: VIEW
Product type: PC
Market positioning: Gaming
Virtual Reality (VR) ready: Yes
Audio output channels: 7.1 channels
Motherboard chipset: AMD B650
Motherboard form factor: ATX
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 3
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: Windows 11 Home
Operating system architecture: 64-bit
Storage
M.2 SSD size: 2280 (22 x 80 mm)
SSD capacity: 1 TB
Total SSDs capacity: 1 TB
Number of storage drives supported: 7
SSD form factor: M.2
NVMe: Yes
Number of storage drives installed: 1
SSD interface: PCI Express
Intel® Optane™ Memory module installed: No
Card reader integrated: No
Number of SSDs installed: 1
Optical drive type: No
Storage media: SSD
Total storage capacity: 1 TB
Ports & interfaces
Intel® Thunderbolt 4: No
Number of front USB ports: 2
Fiber NIC port (Flex I/O): No
Headphone outputs: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 2
Line-in: Yes
Number of rear audio ports: 3
PS/2 ports quantity: 1
Microphone in: Yes
Intel® Thunderbolt 5: No
Line-out: No
Number of front audio ports: 1
Number of rear USB ports: 9
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DisplayPorts quantity: 3
Ethernet LAN (RJ-45) ports: 1
Number of SATA III connectors: 4
S/PDIF out port: No
Combo headphone/mic port: Yes
DC-in jack: No
DVI port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 2.0 ports quantity: 6
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
