Processor
Processor cache: 32 MB
Processor manufacturer: AMD
Number of processors installed: 1
Processor family: AMD Ryzen™ 7
Processor model: 7700
Processor threads: 16
Processor boost frequency: 5.3 GHz
Processor cache type: L3
Processor frequency: 3.8 GHz
Processor cores: 8
Processor socket: Socket AM5
Processor base power: 65 W
Processor generation: AMD Ryzen 7000 Series
Graphics
CUDA: Yes
On-board graphics card family: AMD Radeon Graphics
Discrete graphics card: Yes
Discrete graphics card memory: 8 GB
Graphics card HDMI ports quantity: 1
Discrete graphics card model: NVIDIA GeForce RTX 5060
NVIDIA GameWorks VR: Yes
On-board graphics card: Yes
On-board GPU manufacturer: AMD
On-board graphics card model: AMD Radeon Graphics
NVIDIA G-SYNC: Yes
Number of discrete graphics cards: 1
Discrete graphics memory type: GDDR7
Graphics card DisplayPorts quantity: 3
Discrete GPU manufacturer: NVIDIA
Memory
Maximum internal memory: 256 GB
Non-ECC: Yes
Internal memory type: DDR5-SDRAM
Memory channels: Dual-channel
Memory layout (slots x size): 2 x 16 GB
Internal memory: 32 GB
Memory clock speed: 6000 MHz
Memory slots: 4x DIMM
Design
Product colour: Black
RGB backlighting: Yes
Water cooling system: No
Housing material: Metal, Plastic, Tempered glass
Number of 3.5" bays: 2
VESA mounting: No
Number of 2.5" bays: 3
Chassis type: Midi Tower
Viewing window: Yes
Refurbished: No
Power
Power supply: 650 W
80 PLUS certification: 80 PLUS Gold
Power supply input voltage: 100-240 V
Weight & dimensions
Width: 230 mm
Weight: 10 kg
Height: 500 mm
Depth: 440 mm
Network
Antenna type: 2x2
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN data rates: 100, 1000, 10
Bluetooth version: 5.3
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax)
Internal components: Gigabyte B650 EAGLE AX / NVIDIA GeForce RTX 5060 / WD Blue SN5000 / Phanteks XT View
Performance
Motherboard chipset: AMD B650
Product type: PC
Market positioning: Gaming
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Virtual Reality (VR) ready: Yes
Powered by: VIEW
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 3.x) slots: 3
PCI Express x16 (Gen 4.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
M.2 SSD size: 2280 (22 x 80 mm)
Optical drive type: No
Card reader integrated: No
NVMe: Yes
Number of storage drives installed: 1
SSD capacity: 1 TB
Total SSDs capacity: 1 TB
Number of storage drives supported: 7
SSD form factor: M.2
SSD interface: PCI Express
Intel® Optane™ Memory module installed: No
Total storage capacity: 1 TB
Storage media: SSD
Number of SSDs installed: 1
Ports & interfaces
DC-in jack: No
Number of rear audio ports: 3
Intel® Thunderbolt 5: No
Number of rear USB ports: 9
Fiber NIC port (Flex I/O): No
Line-in: Yes
Number of front audio ports: 1
Number of front USB ports: 2
Combo headphone/mic port: Yes
USB 2.0 ports quantity: 6
Line-out: No
S/PDIF out port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 2
Intel® Thunderbolt 4: No
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 2
Headphone outputs: 1
Number of SATA III connectors: 4
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DVI port: No
DisplayPorts quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
PS/2 ports quantity: 1
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
