Processor
Processor model: 285K
Processor boost frequency: 5.7 GHz
Processor cores: 24
Processor frequency: 3.2 GHz
Processor family: Intel Core Ultra 9
Processor cache type: Smart Cache
Number of processors installed: 1
Efficient-core Max Turbo Frequency: 4.6 GHz
Processor base power: 125 W
Processor threads: 24
Processor generation: Intel Core Ultra (Series 2)
Processor cache: 36 MB
Efficient-core base frequency: 3.2 GHz
Processor socket: LGA 1851 (Socket V1)
Efficient cores: 16
Maximum turbo power: 250 W
Processor manufacturer: Intel
Performance cores: 8
Performance-core Max Turbo Frequency: 5.5 GHz
Performance-core base frequency: 3.7 GHz
Graphics
Graphics card Open GL support: Yes
On-board graphics card model: Intel Graphics
CUDA: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5090
NVIDIA G-SYNC: Yes
NVIDIA GameWorks VR: Yes
Discrete graphics card memory: 32 GB
On-board graphics card family: Intel Graphics
On-board graphics card: Yes
Discrete graphics card: Yes
Discrete GPU manufacturer: NVIDIA
Graphics card DisplayPorts quantity: 3
On-board GPU manufacturer: Intel
Discrete graphics memory type: GDDR7
Number of discrete graphics cards: 1
Graphics card HDMI ports quantity: 1
Memory
Internal memory: 32 GB
Maximum internal memory: 192 GB
Internal memory type: DDR5-SDRAM
Memory channels: Dual-channel
ECC: No
Memory layout (slots x size): 2 x 16 GB
Memory clock speed: 6000 MHz
Memory slots: 4x DIMM
Design
Product colour: Black
Water cooling system: Yes
Housing material: Metal, Plastic, Tempered glass
Chassis type: Midi Tower
VESA mounting: No
Viewing window: Yes
Number of 2.5" bays: 4
Number of 3.5" bays: 4
Refurbished: No
Power
80 PLUS certification: 80 PLUS Gold
Power supply input voltage: 100-240 V
Power supply: 1000 W
Weight & dimensions
Weight: 10 kg
Width: 285 mm
Height: 450 mm
Depth: 446 mm
Network
Bluetooth: Yes
Antenna type: 2x2
Ethernet LAN data rates: 1000, 10, 2500 Mbit/s, 100
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, Wi-Fi 6E (802.11ax), 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN: Yes
Wi-Fi: Yes
Internal components: ASUS PRIME Z890-P WIFI / NVIDIA GeForce RTX 5090 / Kingston Fury Beast RGB / WD Black SN850X / ASUS ROG Strix LC III 360 ARGB / ASUS TUF Gaming 1000W / ASUS TUF Gaming TF120 ARGB / ASUS TUF Gaming GT502
Performance
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Motherboard chipset: Intel Z890
Product type: PC
Market positioning: Gaming
Virtual Reality (VR) ready: Yes
Powered by: ASUS
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Optical drive type: No
Storage media: SSD
M.2 SSD size: 2280 (22 x 80 mm)
Intel® Optane™ Memory module installed: No
SSD interface: PCI Express
Card reader integrated: No
SSD form factor: M.2
NVMe: Yes
SSD capacity: 2 TB
Total SSDs capacity: 2 TB
Number of storage drives installed: 1
Number of storage drives supported: 8
Number of SSDs installed: 1
Total storage capacity: 2 TB
Ports & interfaces
Combo headphone/mic port: Yes
S/PDIF out port: No
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 4
DC-in jack: No
USB 2.0 ports quantity: 4
Number of SATA III connectors: 4
Line-in: Yes
Number of rear USB ports: 8
Intel® Thunderbolt 5: No
Headphone outputs: 1
Line-out: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Fiber NIC port (Flex I/O): No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DVI port: No
HDMI ports quantity: 2
Number of front audio ports: 1
Thunderbolt 4 ports quantity: 1
Intel® Thunderbolt 4: Yes
Microphone in: Yes
Number of front USB ports: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Number of rear audio ports: 3
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
Neural processor unit (NPU)
Total processor performance up to: 36 TOPs
AI software frameworks supported by NPU: OpenVINO, DirectML, WebNN, Windows ML, ONNX RT
GPU performance up to: 8 TOPs
AI datatype support on NPU: Int8
NPU performance up to: 13 TOPs
Windows Studio effects support: Yes
Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
