Processor
Processor threads: 14
Processor family: Intel Core Ultra 5
Number of processors installed: 1
Processor boost frequency: 5.2 GHz
Processor socket: LGA 1851 (Socket V1)
Processor cores: 14
Processor model: 245KF
Processor cache type: Smart Cache
Processor manufacturer: Intel
Processor cache: 24 MB
Processor frequency: 3.6 GHz
Efficient cores: 8
Performance-core base frequency: 4.2 GHz
Performance cores: 6
Efficient-core base frequency: 3.6 GHz
Efficient-core Max Turbo Frequency: 4.6 GHz
Processor generation: Intel Core Ultra (Series 2)
Maximum turbo power: 159 W
Performance-core Max Turbo Frequency: 5.2 GHz
Processor base power: 125 W
Graphics
Graphics card HDMI ports quantity: 1
Ray tracing acceleration: Yes
Graphics card DisplayPorts quantity: 3
Discrete GPU manufacturer: AMD
Number of discrete graphics cards: 1
AMD FreeSync: Yes
CUDA: No
Discrete graphics memory type: GDDR6
NVIDIA G-SYNC: No
Discrete graphics card: Yes
Discrete graphics card memory: 16 GB
Discrete graphics card model: AMD Radeon RX 9060 XT
On-board graphics card: No
NVIDIA GameWorks VR: No
On-board graphics card model: Not available
Memory
Memory slots: 4x DIMM
Memory layout (slots x size): 2 x 16 GB
Memory clock speed: 6000 MHz
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Memory channels: Dual-channel
Maximum internal memory: 256 GB
ECC: No
Design
Housing material: Metal, Plastic
VESA mounting: No
Number of 3.5" bays: 2
Refurbished: No
Chassis type: Midi Tower
Water cooling system: No
Number of 2.5" bays: 5
Viewing window: No
RGB backlighting: Not
Product colour: Black
Power
Power supply: 650 W
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Bronze
Weight & dimensions
Depth: 450 mm
Weight: 12 kg
Height: 500 mm
Width: 230 mm
Network
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
Bluetooth version: 5.3
Antenna type: 2x2
Ethernet LAN data rates: 100, 1000, 10, 2500
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi: Yes
Bluetooth: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
LAN controller: Dragon RTL8125BG
Internal components: ASRock B860 Pro RS WiFi / AMD Radeon RX 9060 XT / WD Blue SN5000 / Phanteks XT Silent
Performance
Virtual Reality (VR) ready: Yes
Market positioning: Gaming
Powered by: SILENT
Motherboard form factor: ATX
Product type: PC
Audio output channels: 7.1 channels
Motherboard chipset: Intel B860
Packaging content
Keyboard included: No
Mouse included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
NVMe: Yes
Total SSDs capacity: 1 TB
Number of SSDs installed: 1
Number of storage drives installed: 1
SSD capacity: 1 TB
Total storage capacity: 1 TB
SSD interface: PCI Express
Storage media: SSD
Card reader integrated: No
SSD form factor: M.2
Intel® Optane™ Memory module installed: No
Number of storage drives supported: 7
Optical drive type: No
M.2 SSD size: 2280 (22 x 80 mm)
Ports & interfaces
Microphone in: Yes
DC-in jack: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
DVI port: No
Line-in: Yes
Combo headphone/mic port: Yes
Line-out: Yes
Number of SATA III connectors: 4
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
Number of rear audio ports: 3
Number of front audio ports: 1
DisplayPorts quantity: 3
Number of rear USB ports: 9
S/PDIF out port: No
USB 3.2 Gen 2x2 Type-C ports quantity: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 7
HDMI ports quantity: 1
Intel® Thunderbolt 5: No
Intel® Thunderbolt 4: No
Fiber NIC port (Flex I/O): No
Number of front USB ports: 2
Special features: The specification and description are for illustrative purposes only.
Other features
Built-in microphone: No
TV tuner integrated: No
Neural processor unit (NPU)
Neural processor unit (NPU): Intel AI Boost
NPU performance up to: 13 TOPs
AI software frameworks supported by NPU: Windows ML, DirectML, ONNX RT, OpenVINO, WebNN
Windows Studio effects support: Yes
Sparsity support: Yes
AI datatype support on NPU: Int8
Total processor performance up to: 22 TOPs
