Processor
Processor cache type: L3
Processor cache: 32 MB
Number of processors installed: 1
Processor model: 7500F
Processor socket: Socket AM5
Processor frequency: 3.7 GHz
Processor family: AMD Ryzen™ 5
Processor manufacturer: AMD
Processor cores: 6
Processor threads: 12
Processor boost frequency: 5 GHz
Processor generation: AMD Ryzen 7000 Series
Processor base power: 65 W
Graphics
Discrete graphics memory type: GDDR7
Discrete GPU manufacturer: NVIDIA
Graphics card HDMI ports quantity: 1
Number of discrete graphics cards: 1
Graphics card DisplayPorts quantity: 3
On-board graphics card: No
Discrete graphics card: Yes
Discrete graphics card memory: 16 GB
NVIDIA G-SYNC: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5060 Ti
On-board graphics card model: Not available
NVIDIA GameWorks VR: Yes
CUDA: Yes
Ray tracing acceleration: Yes
Memory
Memory channels: Dual-channel
Internal memory: 32 GB
Memory clock speed: 6000 MHz
Memory slots: 4x DIMM
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 16 GB
Maximum internal memory: 256 GB
Design
Refurbished: No
Number of 3.5" bays: 3
Water cooling system: No
Number of 2.5" bays: 1
Viewing window: No
Housing material: Metal, Plastic
Chassis type: Mini Tower
VESA mounting: No
Product colour: Black
RGB backlighting: Not
Power
Power supply input voltage: 100-240 V
Power supply: 650 W
80 PLUS certification: 80 PLUS Bronze
Weight & dimensions
Height: 350 mm
Depth: 460 mm
Width: 205 mm
Weight: 10 kg
Network
Bluetooth version: 5.3
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Wi-Fi: Yes
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
Bluetooth: Yes
Ethernet LAN data rates: 10, 100, 1000, 2500 Mbit/s
Antenna type: 2x2
Internal components: ASUS PRIME B850M-A WIFI / NVIDIA GeForce RTX 5060 Ti / WD Blue SN5100 / ASUS Prime AP201
Performance
Virtual Reality (VR) ready: Yes
Powered by: ASUS
Market positioning: Gaming
Product type: PC
Motherboard form factor: micro ATX
Motherboard chipset: AMD B850
Audio output channels: 7.1 channels
Packaging content
Keyboard included: No
Mouse included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
SSD capacity: 1 TB
Number of SSDs installed: 1
Intel® Optane™ Memory module installed: No
Total SSDs capacity: 1 TB
SSD form factor: M.2
NVMe: Yes
SSD interface: PCI Express
Card reader integrated: No
Number of storage drives installed: 1
Total storage capacity: 1 TB
Storage media: SSD
Number of storage drives supported: 7
Optical drive type: No
M.2 SSD size: 2280 (22 x 80 mm)
Ports & interfaces
Number of rear audio ports: 3
Number of rear USB ports: 8
Number of front audio ports: 2
Line-in: Yes
Headphone outputs: 1
Combo headphone/mic port: No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
Intel® Thunderbolt 4: No
Microphone in: Yes
Line-out: Yes
DVI port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 3
Number of SATA III connectors: 4
S/PDIF out port: No
Intel® Thunderbolt 5: No
Fiber NIC port (Flex I/O): No
Number of front USB ports: 3
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
