Processor
Processor model: 9600X
Processor threads: 12
Processor cores: 6
Processor boost frequency: 5.4 GHz
Processor family: AMD Ryzen™ 5
Processor cache: 32 MB
Processor manufacturer: AMD
Processor frequency: 3.9 GHz
Processor cache type: L3
Processor socket: Socket AM5
Processor generation: AMD Ryzen 9000 Series
Number of processors installed: 1
Processor base power: 65 W
Graphics
NVIDIA GameWorks VR: Yes
On-board graphics card model: AMD Radeon Graphics
On-board graphics card: Yes
Discrete graphics card memory: 16 GB
Discrete graphics card model: NVIDIA GeForce RTX 5060 Ti
CUDA: Yes
NVIDIA G-SYNC: Yes
Ray tracing acceleration: Yes
Discrete graphics card: Yes
On-board GPU manufacturer: AMD
Number of discrete graphics cards: 1
Discrete graphics memory type: GDDR7
Graphics card DisplayPorts quantity: 3
Discrete GPU manufacturer: NVIDIA
Graphics card HDMI ports quantity: 1
On-board graphics card family: AMD Radeon Graphics
AMD FreeSync: Yes
Memory
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Memory clock speed: 6000 MHz
Internal memory type: DDR5-SDRAM
Internal memory: 32 GB
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Design
Product colour: Black
VESA mounting: No
RGB backlighting: Not
Number of 2.5" bays: 1
Viewing window: No
Chassis type: Mini Tower
Refurbished: No
Water cooling system: No
Number of 3.5" bays: 3
Housing material: Metal, Plastic
Power
80 PLUS certification: 80 PLUS Bronze
Power supply input voltage: 100-240 V
Power supply: 650 W
Weight & dimensions
Height: 350 mm
Weight: 10 kg
Width: 205 mm
Depth: 460 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11b, 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
Antenna type: 2x2
Cabling technology: 10/100/1000Base-T(X)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN data rates: 2500 Mbit/s, 100, 1000, 10
Wi-Fi: Yes
Bluetooth: Yes
Ethernet LAN: Yes
Bluetooth version: 5.3
Internal components: ASUS PRIME B850M-A WIFI / NVIDIA GeForce RTX 5060 Ti / WD Blue SN5100 / ASUS Prime AP201
Performance
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Motherboard chipset: AMD B850
Market positioning: Gaming
Powered by: ASUS
Product type: PC
Virtual Reality (VR) ready: Yes
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Card reader integrated: No
Number of storage drives supported: 7
Total storage capacity: 1 TB
Optical drive type: No
Storage media: SSD
Number of storage drives installed: 1
Number of SSDs installed: 1
SSD form factor: M.2
SSD capacity: 1 TB
SSD interface: PCI Express
Intel® Optane™ Memory module installed: No
M.2 SSD size: 2280 (22 x 80 mm)
Total SSDs capacity: 1 TB
NVMe: Yes
Ports & interfaces
S/PDIF out port: No
DisplayPorts quantity: 5
Microphone in: Yes
Combo headphone/mic port: No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
Number of SATA III connectors: 4
HDMI ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 2.0 ports quantity: 4
DVI port: No
Intel® Thunderbolt 5: No
Number of rear audio ports: 3
Intel® Thunderbolt 4: No
Line-out: Yes
Number of front audio ports: 2
Fiber NIC port (Flex I/O): No
Number of rear USB ports: 8
Number of front USB ports: 3
Line-in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
