Processor
Processor boost frequency: 5.2 GHz
Maximum turbo power: 159 W
Performance cores: 6
Performance-core base frequency: 4.2 GHz
Efficient cores: 8
Number of processors installed: 1
Processor base power: 125 W
Processor socket: LGA 1851 (Socket V1)
Performance-core Max Turbo Frequency: 5.2 GHz
Efficient-core Max Turbo Frequency: 4.6 GHz
Processor generation: Intel Core Ultra (Series 2)
Efficient-core base frequency: 3.6 GHz
Processor frequency: 3.8 GHz
Processor manufacturer: Intel
Processor family: Intel Core Ultra 5
Processor cache: 24 MB
Processor model: 245KF
Processor threads: 14
Processor cores: 14
Processor cache type: Smart Cache
Graphics
NVIDIA GameWorks VR: Yes
CUDA: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5060 Ti
Discrete graphics card: Yes
Discrete graphics memory type: GDDR7
Graphics card HDMI ports quantity: 1
Graphics card DisplayPorts quantity: 3
Discrete GPU manufacturer: NVIDIA
Number of discrete graphics cards: 1
On-board graphics card model: Not available
Ray tracing acceleration: Yes
Discrete graphics card memory: 16 GB
On-board graphics card: No
NVIDIA G-SYNC: Yes
Memory
Maximum internal memory: 256 GB
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Internal memory: 32 GB
Memory channels: Dual-channel
Memory clock speed: 6000 MHz
Internal memory type: DDR5-SDRAM
Design
Product colour: Black
Chassis type: Mini Tower
Refurbished: No
Number of 2.5" bays: 1
Viewing window: No
Housing material: Metal, Plastic
VESA mounting: No
Water cooling system: No
Number of 3.5" bays: 3
Power
Power supply: 650 W
80 PLUS certification: 80 PLUS Bronze
Power supply input voltage: 100-240 V
Weight & dimensions
Weight: 10 kg
Depth: 460 mm
Width: 205 mm
Height: 350 mm
Network
Ethernet LAN data rates: 100, 1000, 2500 Mbit/s, 10
Antenna type: 2x2
LAN controller: Realtek RTL8125-BG
Bluetooth: Yes
Ethernet LAN: Yes
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi: Yes
Bluetooth version: 5.3
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11g, 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
Internal components: ASRock B860M Pro-A WiFi / NVIDIA GeForce RTX 5060 Ti / WD Blue SN5100 / ASUS Prime AP201
Performance
Audio chip: Realtek ALC897
Motherboard form factor: micro ATX
Motherboard chipset: Intel B860
Audio output channels: 7.1 channels
Market positioning: Gaming
Powered by: ASUS
Virtual Reality (VR) ready: Yes
Product type: PC
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x4 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
Number of SSDs installed: 1
NVMe: Yes
Number of storage drives installed: 1
SSD capacity: 1 TB
Total SSDs capacity: 1 TB
SSD interface: PCI Express
Number of storage drives supported: 7
M.2 SSD size: 2280 (22 x 80 mm)
Intel® Optane™ Memory module installed: No
SSD form factor: M.2
Optical drive type: No
Total storage capacity: 1 TB
Card reader integrated: No
Storage media: SSD
Ports & interfaces
DisplayPorts quantity: 3
S/PDIF out port: No
Number of SATA III connectors: 4
Headphone outputs: 1
Intel® Thunderbolt 4: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Microphone in: Yes
Line-in: Yes
Line-out: Yes
Fiber NIC port (Flex I/O): No
Number of front USB ports: 3
Number of rear USB ports: 6
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
Number of rear audio ports: 3
Number of front audio ports: 2
Combo headphone/mic port: No
HDMI ports quantity: 1
DVI port: No
Intel® Thunderbolt 5: No
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
Neural processor unit (NPU)
AI software frameworks supported by NPU: ONNX RT, WebNN, OpenVINO, DirectML, Windows ML
NPU performance up to: 13 TOPs
Sparsity support: Yes
Windows Studio effects support: Yes
Neural processor unit (NPU): Intel AI Boost
AI datatype support on NPU: Int8
Total processor performance up to: 22 TOPs
