Processor
Processor boost frequency: 4.2 GHz
Processor family: AMD Ryzen™ 5
Number of processors installed: 1
Processor manufacturer: AMD
Processor frequency: 3.6 GHz
Processor threads: 12
Processor cores: 6
Processor socket: Socket AM4
Processor model: 5500
Processor generation: AMD Ryzen 5000 Series
Processor cache type: L3
Processor cache: 16 MB
Processor base power: 65 W
Graphics
Discrete graphics card model: AMD Radeon RX 6500 XT
CUDA: No
Ray tracing acceleration: Yes
AMD FreeSync: Yes
Discrete GPU manufacturer: AMD
Graphics card HDMI ports quantity: 1
Discrete graphics memory type: GDDR6
On-board graphics card model: Not available
NVIDIA GameWorks VR: No
Number of discrete graphics cards: 1
Graphics card DisplayPorts quantity: 3
NVIDIA G-SYNC: No
Discrete graphics card memory: 4 GB
Discrete graphics card: Yes
On-board graphics card: No
Memory
Maximum internal memory: 128 GB
Memory layout (slots x size): 2 x 8 GB
Memory slots: 4x DIMM
Internal memory: 16 GB
Memory channels: Dual-channel
ECC: No
Internal memory type: DDR4-SDRAM
Design
Product colour: Black
RGB backlighting: Yes
Refurbished: No
Number of 3.5" bays: 2
Certified refurbished: No
Housing material: Metal, Plastic, Tempered glass
Water cooling system: No
Viewing window: Yes
Number of 2.5" bays: 3
VESA mounting: No
Chassis type: Midi Tower
Power
Power supply input voltage: 100-240 V
Power supply: 650 W
80 PLUS certification: 80 PLUS Bronze
Weight & dimensions
Width: 230 mm
Weight: 10 kg
Depth: 440 mm
Height: 500 mm
Network
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Bluetooth: No
LAN controller: Realtek RTL8111H
Wi-Fi: Yes
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), 802.11b, 802.11a, Wi-Fi 4 (802.11n)
Cabling technology: 10/100/1000Base-T(X)
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Internal components: ASUS PRIME B550M-A / AMD Radeon RX 6500 XT / WD Green SN3000 / Phanteks XT View
Performance
Motherboard chipset: AMD B550
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Audio chip: Realtek ALC887 / Realtek ALC897
Powered by: VIEW
Virtual Reality (VR) ready: Yes
Market positioning: Gaming
Product type: PC
Packaging content
Mouse included: No
Keyboard included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Storage
SSD interface: PCI Express
SSD form factor: M.2
Number of storage drives installed: 1
SSD capacity: 1 TB
NVMe: Yes
Intel® Optane™ Memory module installed: No
M.2 SSD size: 2280 (22 x 80 mm)
Total SSDs capacity: 1 TB
Total storage capacity: 1 TB
Number of SSDs installed: 1
Optical drive type: No
Card reader integrated: No
Number of storage drives supported: 6
Storage media: SSD
Ports & interfaces
DisplayPorts quantity: 3
S/PDIF out port: No
DC-in jack: No
Number of rear USB ports: 6
Number of rear audio ports: 3
Intel® Thunderbolt 5: No
Number of front audio ports: 1
Line-out: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Line-in: Yes
Ethernet LAN (RJ-45) ports: 1
Number of SATA III connectors: 4
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Combo headphone/mic port: Yes
DVI port: No
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
Intel® Thunderbolt 4: No
Microphone in: Yes
PS/2 ports quantity: 1
Number of front USB ports: 2
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Built-in microphone: No
