Processor
Number of processors installed: 1
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Processor cache: 36 MB
Processor frequency: 3.2 GHz
Processor boost frequency: 5.5 GHz
Processor cache type: Smart Cache
Processor threads: 24
Processor cores: 24
Processor family: Intel Core Ultra 7
Processor model: 270K Plus
Processor base power: 125 W
Processor generation: Intel Core Ultra (Series 2)
Efficient-core base frequency: 3.2 GHz
Maximum turbo power: 250 W
Performance-core base frequency: 3.7 GHz
Efficient cores: 16
Performance cores: 8
Efficient-core Max Turbo Frequency: 4.7 GHz
Graphics
On-board graphics card: Yes
Discrete graphics card: Yes
On-board graphics card family: Intel® Graphics
Discrete graphics card model: AMD Radeon RX 9070 XT
NVIDIA G-SYNC: No
Discrete graphics memory type: GDDR6
CUDA: No
NVIDIA GameWorks VR: No
On-board graphics card model: Intel® Graphics
Graphics card DisplayPorts quantity: 3
Discrete graphics card memory: 16 GB
Number of discrete graphics cards: 1
Graphics card HDMI ports quantity: 1
Discrete GPU manufacturer: AMD
On-board graphics card cores: 4
On-board GPU manufacturer: Intel
Ray tracing acceleration: Yes
Memory
Memory slots: 4x DIMM
Memory layout (slots x size): 2 x 16 GB
Maximum internal memory: 192 GB
Non-ECC: Yes
Memory channels: Dual-channel
Internal memory: 32 GB
Internal memory type: DDR5-SDRAM
Memory clock speed: 6000 MHz
Design
Housing material: Metal, Plastic, Tempered glass
Chassis type: Midi Tower
VESA mounting: No
Number of 2.5" bays: 5
Water cooling system: Yes
Viewing window: Yes
Number of 3.5" bays: 2
Refurbished: No
Product colour: Black
RGB backlighting: Yes
Certified refurbished: No
Power
80 PLUS certification: 80 PLUS Gold
Power supply: 750 W
Power supply input voltage: 100-240 V
Weight & dimensions
Depth: 440 mm
Width: 230 mm
Height: 500 mm
Weight: 12 kg
Network
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi standards: 802.11g, 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Ethernet LAN: Yes
Bluetooth version: 5.4
Ethernet LAN data rates: 10, 1000 Mbit/s, 2500, 100
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Antenna type: 2x2
Internal components: ASUS PRIME Z890-P WIFI / AMD Radeon RX 9070 XT / WD Blue SN5100 / Phanteks XT View
Performance
Market positioning: Gaming
Product type: PC
Motherboard chipset: Intel Z890
Powered by: VIEW
Virtual Reality (VR) ready: Yes
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Packaging content
Keyboard included: No
Mouse included: No
Expansion slots
PCI Express x16 (Gen 4.x) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Audio
Built-in microphone: No
Storage
Card reader integrated: No
Number of storage drives installed: 1
Number of storage drives supported: 8
Total SSDs capacity: 1 TB
SSD interface: PCI Express
Intel® Optane™ Memory module installed: No
NVMe: Yes
Total storage capacity: 1 TB
Number of SSDs installed: 1
SSD form factor: M.2
SSD capacity: 1 TB
Optical drive type: No
Storage media: SSD
M.2 SSD size: 2280 (22 x 80 mm)
Ports & interfaces
Microphone in: Yes
Headphone outputs: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Number of SATA III connectors: 4
Ethernet LAN (RJ-45) ports: 1
Combo headphone/mic port: Yes
USB 2.0 ports quantity: 4
DC-in jack: No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DVI port: No
S/PDIF out port: No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Line-in: Yes
DisplayPorts quantity: 3
Line-out: Yes
HDMI ports quantity: 1
Intel® Thunderbolt 4: Yes
Number of front USB ports: 2
Thunderbolt 4 ports quantity: 1
Fiber NIC port (Flex I/O): No
Number of rear USB ports: 8
Number of front audio ports: 1
Number of rear audio ports: 3
Intel® Thunderbolt 5: No
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Neural processor unit (NPU)
AI software frameworks supported by NPU: WebNN, Windows ML, DirectML, ONNX RT, OpenVINO
AI datatype support on NPU: Int8
Neural processor unit (NPU): Intel AI Boost
NPU performance up to: 13 TOPs
Total processor performance up to: 36 TOPs
GPU performance up to: 8 TOPs
