Processor
Processor frequency: 3.2 GHz
Processor manufacturer: Intel
Processor cache: 36 MB
Processor family: Intel Core Ultra 7
Processor threads: 24
Efficient-core Max Turbo Frequency: 4.7 GHz
Processor cache type: Smart Cache
Efficient-core base frequency: 3.2 GHz
Processor boost frequency: 5.5 GHz
Efficient cores: 16
Processor cores: 24
Number of processors installed: 1
Processor socket: LGA 1851 (Socket V1)
Maximum turbo power: 250 W
Processor base power: 125 W
Performance-core base frequency: 3.7 GHz
Processor generation: Intel Core Ultra (Series 2)
Processor model: 270K Plus
Performance cores: 8
Graphics
On-board graphics card model: Intel® Graphics
NVIDIA GameWorks VR: Yes
On-board graphics card: Yes
NVIDIA G-SYNC: Yes
Discrete GPU manufacturer: NVIDIA
Discrete graphics card model: NVIDIA GeForce RTX 5070 Ti
On-board graphics card family: Intel® Graphics
Discrete graphics card memory: 16 GB
On-board GPU manufacturer: Intel
Number of discrete graphics cards: 1
On-board graphics card cores: 4
Discrete graphics memory type: GDDR7
Ray tracing acceleration: Yes
Graphics card HDMI ports quantity: 1
Graphics card DisplayPorts quantity: 3
Discrete graphics card: Yes
CUDA: Yes
Memory
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 16 GB
Memory clock speed: 6000 MHz
Non-ECC: Yes
Maximum internal memory: 192 GB
Memory channels: Dual-channel
Memory slots: 4x DIMM
Internal memory: 32 GB
Design
Water cooling system: Yes
RGB backlighting: Yes
Refurbished: No
Number of 3.5" bays: 2
Chassis type: Midi Tower
VESA mounting: No
Number of 2.5" bays: 5
Viewing window: Yes
Certified refurbished: No
Housing material: Metal, Plastic, Tempered glass
Product colour: Black
Power
Power supply: 750 W
Power supply input voltage: 100-240 V
80 PLUS certification: 80 PLUS Gold
Weight & dimensions
Weight: 12 kg
Height: 500 mm
Width: 230 mm
Depth: 440 mm
Network
Wi-Fi standards: 802.11b, Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 7 (802.11be)
Ethernet LAN data rates: 1000 Mbit/s, 2500, 10, 100
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Cabling technology: 10/100/1000Base-T(X)
Bluetooth version: 5.4
Antenna type: 2x2
Ethernet LAN: Yes
Bluetooth: Yes
Internal components: ASUS PRIME Z890-P WIFI / NVIDIA GeForce RTX 5070 Ti / WD Blue SN5100 / Phanteks XT View
Performance
Audio output channels: 7.1 channels
Powered by: VIEW
Motherboard form factor: ATX
Market positioning: Gaming
Virtual Reality (VR) ready: Yes
Motherboard chipset: Intel Z890
Product type: PC
Packaging content
Keyboard included: No
Mouse included: No
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 3
Display
Display included: No
Bundled software: Bitdefender Internet Security
Software
Operating system installed: No
Audio
Built-in microphone: No
Storage
Optical drive type: No
Total storage capacity: 1 TB
Card reader integrated: No
Number of SSDs installed: 1
SSD interface: PCI Express
Intel® Optane™ Memory module installed: No
NVMe: Yes
SSD form factor: M.2
M.2 SSD size: 2280 (22 x 80 mm)
Storage media: SSD
Total SSDs capacity: 1 TB
Number of storage drives supported: 8
Number of storage drives installed: 1
SSD capacity: 1 TB
Ports & interfaces
USB 2.0 ports quantity: 4
S/PDIF out port: No
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Number of rear audio ports: 3
Number of front audio ports: 1
Fiber NIC port (Flex I/O): No
Combo headphone/mic port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DVI port: No
Headphone outputs: 1
Number of rear USB ports: 8
Intel® Thunderbolt 4: Yes
HDMI ports quantity: 1
Intel® Thunderbolt 5: No
Number of front USB ports: 2
Microphone in: Yes
Line-in: Yes
DC-in jack: No
Thunderbolt 4 ports quantity: 1
Line-out: Yes
Special features: The specification and description are for illustrative purposes only.
Other features
TV tuner integrated: No
Neural processor unit (NPU)
AI software frameworks supported by NPU: Windows ML, DirectML, WebNN, ONNX RT, OpenVINO
AI datatype support on NPU: Int8
Neural processor unit (NPU): Intel AI Boost
NPU performance up to: 13 TOPs
GPU performance up to: 8 TOPs
Total processor performance up to: 36 TOPs
