Design Fan diameter: 12 cm Cooling type: Active Product colour: Black Number of fans: 1 fan(s)
Power AC input voltage: 220 - 240 V Combined power (+5Vsb): 12.5 W Max output current (+12V): 42 A AC input frequency: 50 - 60 Hz Combined power (+12V): 504 W Max output current (+3.3V): 20 A Combined power (+5V): 100 W Combined power (+3.3V): 100 W Total power: 550 W Input current: 4 A Combined power (-12V): 3.6 W Power Factor Correction (PFC) type: Active Efficiency: 88% Max output current (+5V): 20 A Max output current (+5Vsb): 2.5 A Power factor: 0.9 Max output current (-12V): 0.3 A
Performance Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 2.4 80 PLUS certification: 80 PLUS Bronze
Packaging data Package type: Box Package width: 230 mm Package height: 95 mm Package depth: 195 mm Cables included: AC
Ports & interfaces Motherboard power connector: 20+4 pin ATX CPU power cable length: 55 cm PCI Express connector: Yes Number of SATA power connectors: 4 SATA power cable length: 550 PCI Express power connectors (6+2 pin): 1 ATX power connector (20+4 pin): Yes Number of PATA power connectors: 2 CPU power connector (4+4 pin): Yes Motherboard power cable length: 50 cm PCI Express power cable length: 45 cm
Other features Manual: Yes
Logistics data Master (outer) case height: 215 mm Master (outer) case length: 495 mm Master (outer) case width: 250 mm
