Design
Product colour: Black
Number of heat pipes: 5
Material: Aluminium
Fan connector: 4-pin
Fins material: Aluminium
Illumination colour: Multi
Illumination LED: Yes
Power
Thermal Design Power (TDP): 150 W
Starting voltage: 5 V
Rated voltage: 12 V
Rated current: 0.8 A
Power consumption (typical): 9.6 W
Weight & dimensions
Width: 100 mm
Height: 145 mm
Heat pipes diameter: 6 mm
Fan dimensions (W x D x H): 60 x 60 x 45 mm
Performance
Supported processor sockets: LGA 2066, Socket FM2, Socket AM2, LGA 1200 (Socket H5), Socket AM4, Socket AM2+, Socket AM3, LGA 2011 (Socket R), Socket AM3+, Socket FM1, LGA 775 (Socket T)
Maximum air pressure: 2.13 mmH2O
Rotational speed (min): 1200 RPM
Noise level (high speed): 30 dB
Noise level (low speed): 18 dB
Maximum airflow: 74.3 cfm
Minimum airflow (imperial): 39.7 cfm
Fan diameter: 6 cm
Rotational speed (max): 3000 RPM
Bearing type: Hydraulic
Type: Internal
Suitable for: Processor
Minimum air pressure: 0.91 mmH2O
Compatible processor series: Not supported
Mean time between failures (MTBF): 60000 h
Quantity per pack: 1 pc(s)
