Design Fan location: Top Cooling type: Active Number of fans: 1 fan(s) Product colour: Black Fan diameter: 12 cm
Power AC input frequency: 47 - 63 Hz Combined power (+12V): 600 W Input current: 5 A Max output current (+12V): 50 A Max output current (+5Vsb): 2.5 A Combined power (+3.3V): 120 W Total power: 650 W Combined power (+5Vsb): 12.5 W Combined power (+5V): 120 W Combined power (-12V): 3.6 W AC input voltage: 230 V Max output current (+5V): 17 A Max output current (-12V): 0.3 A Power protection features: Short circuit, Over voltage, Over power, Under voltage Max output current (+3.3V): 20 A
Performance Purpose: PC Power supply unit (PSU) form factor: ATX
Packaging data Package type: Box
Ports & interfaces CPU power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 2 PCI Express power cable length: 40 cm SATA power cable length: 300, 150 Number of PATA power connectors: 3 Number of SATA power connectors: 4 ATX power connector (20+4 pin): Yes Motherboard power connector: 20+4 pin ATX
Logistics data Master (outer) case length: 410 mm Products per master (outer) case: 10 pc(s) Master (outer) case height: 250 mm Master (outer) case width: 500 mm
