Design
Glass thickness: 3.1 mm
Market positioning: Business
Housing material: Metal
Product colour: Black
Power
European Product Registry for Energy Labelling (EPREL) code: 456260
Power consumption (typical): 10 W
Power supply type: External
Power consumption (standby): 0.8 W
Power consumption (off): 0.3 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 10 - 90%
Weight & dimensions
Width (without stand): 380 mm
Weight (with stand): 5.8 kg
Height (without stand): 49.5 mm
Weight (without stand): 3.9 kg
Depth (without stand): 318 mm
Height (with stand): 214.2 mm
Width (with stand): 380 mm
Depth (with stand): 343.4 mm
Performance
Operating system installed: Windows 10
Operating hours (hours/days): 24/7
AMD FreeSync: No
Linux operating systems supported: Yes
Windows operating systems supported: Windows XP, Windows CE, Windows Vista, Windows 2000
Mac operating systems supported: Yes
NVIDIA G-SYNC: No
Packaging data
Package height: 277 mm
Package width: 450 mm
Package weight: 8 kg
Package depth: 418 mm
Packaging content
Stand included: Yes
Cables included: HDMI, USB, AC, VGA
Display
Colour gamut standard: NTSC
Backlight type: LED
Touchscreen: Yes
Digital vertical frequency: 50 - 75 Hz
Display technology: LCD
Display diagonal (metric): 43.1 cm
NTSC coverage (typical): 72%
Touchscreen technology: Projected capacitive system
Touch technology: Multi-touch
Panel type: TN
Anti-glare screen: Yes
Surface hardness: 7H
Haze rate: 25%
Contrast ratio (typical): 1000:1
Touchscreen type: Tabletop
Number of simultaneous touchpoints: 10
Digital horizontal frequency: 31 - 80 kHz
Display resolution: 1280 x 1024 pixels
Native aspect ratio: 16:9
Viewing angle, horizontal: 170°
Pixel pitch: 0.264 x 0.264 mm
HD type: SXGA
Response time: 3 ms
Display number of colours: 16.7 million colours
Viewing angle, vertical: 160°
Screen shape: Flat
Display brightness (typical): 250 cd/m²
Display diagonal: 43.2 cm (17")
Multimedia
Built-in speaker(s): No
Built-in camera: No
Built-in microphone: No
Ergonomics
VESA mounting: Yes
Wall mountable: Yes
Tilt adjustment: Yes
Plug and Play: Yes
Panel mounting interface: 100 x 100 mm
Height adjustment: No
Cable lock slot type: Kensington
Tilt angle range: -5 - 90°
Cable lock slot: Yes
Ports & interfaces
HDMI: Yes
USB upstream port type: USB Type-B
VGA (D-Sub) ports quantity: 1
Number of upstream ports: 1
Built-in USB hub: No
HDMI version: 1.4
Headphone out: No
HDMI ports quantity: 1
DisplayPorts quantity: 1
Certification: CE, LVD, WEEE, RoHS, REACH, EAC
Other features
Compliance certificates: Low Voltage Directive (LVD), RoHS, CE, REACH, WEEE
Mobile operating systems supported: Android 4.0, Android 2.0
International Protection (IP) code: IP65
Logistics data
Harmonized System (HS) code: 85285210
Sustainability
Sustainability compliance: Yes
