Design
Product colour: Black
Market positioning: Industrial
Housing material: Metal
Power
Energy efficiency scale: A to G
Power consumption (standby): 0.5 W
Power consumption (typical): 21 W
European Product Registry for Energy Labelling (EPREL) code: 444576
Energy efficiency class (SDR): E
Energy consumption (SDR) per 1000 hours: 14 kWh
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Height (with stand): 420.2 mm
Width (with stand): 445.4 mm
Depth (with stand): 175 mm
Weight (without stand): 6 kg
Depth (without stand): 64.5 mm
Weight (with stand): 6.8 kg
Width (without stand): 445.4 mm
Height (without stand): 383.9 mm
Performance
NVIDIA G-SYNC: No
AMD FreeSync: No
Packaging data
Package weight: 9.3 kg
Package height: 526 mm
Package depth: 225 mm
Package width: 552 mm
Packaging content
Cables included: VGA, Audio (3.5mm), AC
Quick start guide: Yes
Stand included: Yes
Display
Viewing angle, vertical: 160°
Screen shape: Flat
Display brightness (typical): 250 cd/m²
Contrast ratio (dynamic): 20000000:1
Viewing angle, horizontal: 170°
HD type: SXGA
Display diagonal: 48.3 cm (19")
Digital horizontal frequency: 24 - 83 kHz
Response time: 3 ms
Supported graphics resolutions: 1280 x 1024 (SXGA)
Native aspect ratio: 5:4
Display resolution: 1280 x 1024 pixels
Display number of colours: 16.78 million colours
Pixel pitch: 0.294 x 0.294 mm
Display technology: LED
Backlight type: LED
Digital vertical frequency: 50 - 75 Hz
NTSC coverage (typical): 72%
Panel type: TN
Touchscreen: No
Contrast ratio (typical): 1000:1
Surface hardness: 9H
Colour gamut standard: NTSC
Multimedia
Built-in speaker(s): Yes
Number of speakers: 2
Built-in camera: No
RMS rated power: 4 W
Ergonomics
Cable lock slot type: Kensington
Tilt angle range: 0 - 20°
Cable lock slot: Yes
VESA mounting: Yes
Tilt adjustment: Yes
Height adjustment: No
Panel mounting interface: 100 x 100 mm, 75 x 75 mm
Picture-in-Picture: Yes
Ports & interfaces
DisplayPorts quantity: 1
DC-in jack: Yes
DisplayPort version: 1.2a
DVI-D ports quantity: 1
DVI port: Yes
HDMI version: 1.4
Built-in USB hub: No
Audio input: Yes
HDMI: Yes
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
Other features
AC adapter included: Yes
Compliance certificates: RoHS, CE, WEEE, Low Voltage Directive (LVD), REACH
Logistics data
Harmonized System (HS) code: 85285210
Safety warning
Warnings: Do not place heavy objects on the monitor to avoid damage., Do not open the monitor case to prevent electric shock., Avoid prolonged staring at the screen at high brightness to prevent eye fatigue.
