Technical details
Warranty period: 2 year(s)
Design
Product colour: Black
Fan connector: 4-pin
Number of heat pipes: 7
Material: Plastic, Copper, Aluminium
Illumination colour: Multi
Illumination LED: Yes
Radiator material: Aluminum
Number of fan blades: 9
LED connector type: 3-pin
Power
LED voltage: 0.5 V
Rated voltage: 12 V
Rated current: 0.13 A
Thermal Design Power (TDP): 250 W
Weight & dimensions
Weight: 1.19 kg
Radiator height: 15.8 cm
Radiator width: 13.7 cm
Fan thickness: 2.5 cm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Radiator depth: 12 cm
Fan 2 dimensions (W x D x H): 120 x 120 x 25 mm
Performance
Type: Air cooler
Supported processor sockets: LGA 2011 (Socket R), LGA 1200 (Socket H5), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1700, Socket AM4, LGA 1151 (Socket H4), LGA 2066, LGA 1150 (Socket H3), Socket AM5
Maximum airflow: 52.91 cfm
Rotational speed (min): 500 RPM
Rotational speed (max): 2000 RPM
Suitable location: Processor
Fan diameter 2: 12 cm
Quantity per pack: 1 pc(s)
Fan diameter: 12 cm
Bearing type: Ceramic bearing
Noise level (low speed): 14.2 dB
Maximum air pressure: 1.75 mmH2O
Fan's mean time to failure (MTTF): 40000 h
Noise level (high speed): 31.8 dB
Fan 2 noise level (high speed): 31.8 dB
Fan 2 maximum airflow: 52.91 cfm
Fan 2 rotational speed (min): 500 RPM
Fan 2 noise level (low speed): 14.2 dB
Fan 2 maximum air pressure: 1.75 mmH2O
Fan 2 rotational speed (max): 2000 RPM
Packaging content
Mounting kit: Yes
CPU bracket(s): Yes
Installation instruction: Yes
Screws included: Yes
Safety warning
Warnings: Do not use the product in damp or wet areas., Ensure the unit is unplugged from the power supply before any maintenance., Store away from children.
