Power AC input voltage: 230 V Power protection features: Short circuit, Over voltage, Under voltage, Over current, Over power Max output current (+12V): 19 A Combined power (+5V): 210 W Combined power (+3.3V): 210 W Combined power (-12V): 18.5 W Combined power (+5Vsb): 18.5 W Max output current (+5Vsb): 2.5 A Input current: 5 A Max output current (+5V): 28 A Total power: 420 W Efficiency: 70% Max output current (+3.3V): 24 A Max output current (-12V): 0.5 A AC input frequency: 50 Hz Combined power (+12V): 228 W
Operational conditions Operating temperature (T-T): 5 - 50 °C
Weight & dimensions Height: 85 mm Depth: 140 mm Weight: 1.04 kg Width: 150 mm Certification: REACH, CE
Performance ATX version: 2.31 Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: ATX Purpose: PC
Packaging data Package width: 151 mm Package weight: 1.05 kg Package depth: 196 mm Package type: Box Package height: 86 mm
Ports & interfaces Number of SATA power connectors: 3 CPU P4 connector (4-pin): 1 ATX Power connector (20-pin): Y Motherboard power connector: 20+4 pin ATX Peripheral (Molex) power connectors (4-pin): 2
