Design Fan location: Top Cooling type: Active Product colour: Grey On/off switch: Yes Number of fans: 1 fan(s) Fan diameter: 12 cm
Power Combined power (+5Vsb): 18.5 W Power protection features: Short circuit, Overheating, Over power, Over voltage, Over current AC input voltage: 230 V Max output current (+5V): 34 A Max output current (+5Vsb): 2.5 A Efficiency: 70% Combined power (+5V): 250 W Total power: 500 W Max output current (+3.3V): 30 A Input current: 5 A Combined power (-12V): 18.5 W Max output current (-12V): 0.5 A Peak power: 500 W Combined power (+12V): 264 W Max output current (+12V): 22 A Combined power (+3.3V): 250 W
Operational conditions Operating temperature (T-T): 5 - 50 °C
Weight & dimensions Depth: 140 mm Width: 150 mm Weight: 1.03 kg Height: 85 mm Certification: CE
Performance Mean time between failures (MTBF): 100000 h Purpose: PC Power supply unit (PSU) form factor: ATX ATX version: 2.31
Packaging data Package height: 95 mm Package depth: 220 mm Package width: 160 mm Package type: Box Manual: Yes Package weight: 1.1 kg
Ports & interfaces Peripheral (Molex) power cable length: 300 Cabling type: Non-Modular SATA power cable length: 300 Number of SATA power connectors: 3 Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 1 CPU power cable length: 45 cm CPU P4 connector (4-pin): 1 ATX power connector (20+4 pin): Yes Motherboard power connector: 20+4 pin ATX
