Design Product colour: Grey Number of fans: 1 fan(s) Fan diameter: 12 cm On/off switch: Yes
Power Combined power (+12V): 252 W Max output current (+5V): 34 A Power Factor Correction (PFC) type: Passive Combined power (+3.3V): 250 W Max output current (+12V): 21 A Combined power (+5V): 250 W Input current: 5 A Total power: 500 W AC input voltage: 220 V Max output current (+3.3V): 30 A
Operational conditions Operating temperature (T-T): 5 - 50 °C
Weight & dimensions Height: 85 mm Depth: 140 mm Weight: 1.01 kg Width: 150 mm Certification: CE, RoHS, REACH
Performance Purpose: PC Power supply unit (PSU) form factor: ATX ATX version: 2.31 Mean time between failures (MTBF): 100000 h Supported motherboard form factors: ATX
Packaging data Package height: 95 mm Package type: Box Package weight: 1.09 kg Manual: Yes Package depth: 220 mm Package width: 160 mm
Packaging content Cables included: Peripheral (Molex) to SATA 3.3, SATA
Ports & interfaces EPS power connector (8-pin): No Number of SATA power connectors: 3 Peripheral (Molex) power cable length: 300 Motherboard power connector: 20+4 pin ATX SATA power cable length: 300 Peripheral (Molex) power connectors (4-pin): 2 ATX power connector (12+4 pin): Yes
Other features Fan controller: Yes Number of cables: 4 Warranty card: Yes Voltage tolerance: 70%
Safety warning Warnings: Avoid contact of the product with water or other liquids., Do not open the case - risk of electric shock., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
