Design Cooling type: Active Product colour: Grey Fan location: Top Fan diameter: 12 cm On/off switch: Yes Number of fans: 1 fan(s)
Power Max output current (+5Vsb): 2.5 A Combined power (+12V): 288 W Max output current (+5V): 36 A Combined power (+5Vsb): 18.5 W AC input voltage: 230 V Combined power (-12V): 18.5 W Input current: 5 A Power protection features: Overheating, Over power, Short circuit, Over voltage, Over current Total power: 550 W Max output current (+12V): 24 A Combined power (+3.3V): 280 W Combined power (+5V): 280 W Efficiency: 70% Peak power: 550 W Max output current (+3.3V): 33 A Max output current (-12V): 0.5 A
Operational conditions Operating temperature (T-T): 5 - 50 °C
Weight & dimensions Width: 150 mm Weight: 1.04 kg Height: 85 mm Depth: 140 mm Certification: CE, REACH
Performance Mean time between failures (MTBF): 100000 h Purpose: PC Supported motherboard form factors: ATX ATX version: 2.31 Power supply unit (PSU) form factor: ATX
Packaging data Package width: 160 mm Package height: 95 mm Package type: Box Package weight: 1.12 kg Manual: Yes Package depth: 220 mm
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 Peripheral (Molex) power cable length: 300 CPU P4 connector (4-pin): 1 PCI Express power connectors (6-pin): 1 Number of SATA power connectors: 3 SATA power cable length: 300 CPU power cable length: 45 cm Motherboard power connector: 20+4 pin ATX Cabling type: Non-Modular
