Design Number of fans: 1 fan(s) Fan diameter: 12 cm Product colour: Grey
Power Combined power (+5V): 300 W Max output current (+3.3V): 35 A Total power: 600 W Power protection features: Over power, Under voltage, Over current, Short circuit, Over voltage Max output current (+5V): 38 A Combined power (+5Vsb): 18.5 W Power Factor Correction (PFC) type: Passive Efficiency: 70% Max output current (+12V): 36 A Combined power (+3.3V): 300 W Combined power (+12V): 312 W AC input frequency: 50 Hz Combined power (-12V): 18.5 W Max output current (+5Vsb): 2.5 A AC input voltage: 230 V Input current: 5 A Max output current (-12V): 0.5 A
Operational conditions Operating temperature (T-T): 5 - 50 °C
Weight & dimensions Width: 150 mm Depth: 140 mm Weight: 1.12 kg Height: 87 mm Certification: REACH, CE, RoHS
Performance Power supply unit (PSU) form factor: ATX ATX version: 2.31 Mean time between failures (MTBF): 100000 h Purpose: PC
Packaging data Package type: Box Package depth: 220 mm Package weight: 1.19 kg Package height: 95 mm Package width: 160 mm
Ports & interfaces PCI Express power connectors (6+2 pin): 1 Motherboard power connector: 20+4 pin ATX Number of SATA power connectors: 4 EPS power connector (8-pin): No Peripheral (Molex) power connectors (4-pin): 2
