Technical details
Compliance certificates: RoHS
Design
Cooling type: Active
On/off switch: Yes
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Fan location: Side
Product colour: Grey
Power
Max output current (+5Vsb): 2.5 A
Power Factor Correction (PFC) type: Passive
AC input frequency: 50 Hz
Combined power (-12V): 18.5 W
AC input voltage: 220 - 230 V
Max output current (+12V): 32 A
Power protection features: Short circuit, Over voltage, Over current, Over power, Overheating
Efficiency: 70%
Combined power (+12V): 384 W
Max output current (+5V): 38 A
Combined power (+3.3V): 300 W
Total power: 700 W
Max output current (-12V): 0.5 A
Max output current (+3.3V): 35 A
Combined power (+5Vsb): 18.5 W
Combined power (+5V): 300 W
Operational conditions
Operating temperature (T-T): 5 - 50 °C
Weight & dimensions
Height: 85 mm
Depth: 160 mm
Weight: 1.26 kg
Width: 150 mm
Certification: CE, FCC, RoHS, REACH
Performance
Purpose: PC
ATX version: 2.31
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
Packaging data
Package width: 180 mm
Package height: 95 mm
Package type: Box
Package weight: 1.33 kg
Package depth: 260 mm
Ports & interfaces
SATA power cable length: 300, 150
PCI Express power connectors (6+2 pin): 2
Peripheral (Molex) power connectors (4-pin): 2
Number of SATA power connectors: 5
Peripheral (Molex) power cable length: 300, 150
Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 45 cm
Cabling type: Non-Modular
EPS power connector (4+4 pin): Yes
PCI Express power cable length: 45 cm
Other features
EPS cable length: 60 cm
