Design Fan location: Top On/off switch: Yes Cooling type: Active Fan diameter: 12 cm Number of fans: 1 fan(s) Product colour: Black
Power Combined power (+12V): 468 W Power protection features: Over current, Overheating, Short circuit, Over voltage, Under total voltage, Over power Max output current (+5V): 12 A Total power: 468 W Efficiency: 80% Combined power (+5V): 100 W Max output current (+3.3V): 12 A Combined power (+3.3V): 100 W Max output current (+12V): 33 A Peak power: 500 W AC input voltage: 230 V
Operational conditions Operating temperature (T-T): 5 - 50 °C
Weight & dimensions Depth: 150 mm Width: 145 mm Height: 85 mm Weight: 1.32 kg
Performance 80 PLUS certification: 80 PLUS Purpose: PC ATX version: 2.31 Power supply unit (PSU) form factor: ATX
Packaging data Package width: 180 mm Package weight: 1.88 kg Package height: 100 mm Package depth: 235 mm Package type: Box
Ports & interfaces Cabling type: Fully-Modular SATA power cable length: 450 mm PCI Express power connectors (6+2 pin): 2 Motherboard power cable length: 50 cm EPS power connector (8-pin): Yes Peripheral (Molex) power connectors (4-pin): 2 ATX power connector (20+4 pin): Yes ATX Power connector (24-pin): Yes CPU power connector (4+4 pin): Yes PCI Express connector: Yes Number of SATA power connectors: 4 Motherboard power connector: 24-pin ATX EPS power connector (4+4 pin): Yes CPU power cable length: 55 cm Peripheral (Molex) power cable length: 450 mm
