Features
Power protection features: Overload, Overdischarge, Overcharge
Output power: 480 W
Audible alarm(s): Yes
Output power capacity: 0.8 kVA
Surge protection features: Network
Noise level: 40 dB
UPS topology: Line-Interactive
Output voltage regulation: 10%
Auto-restart: Yes
Automatic Voltage Regulation (AVR): Yes
Surge protection: Yes
Auto power off: Yes
Input operation voltage (min): 162 V
Input operation voltage (max): 290 V
Input frequency: 50/60 Hz
Waveform: Sine
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Design
LED indicators: Yes
Form factor: Compact
Product colour: Black
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 90 mm
Depth: 285 mm
Width: 202 mm
Weight: 5.2 kg
Packaging data
Package width: 238 mm
Package volume: 10555.8 cm³
Packaging content
Manual: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
USB port: Yes
AC outlets quantity: 7 AC outlet(s)
Power plug: C14 coupler
USB 2.0 ports quantity: 2
AC outlet types: C13 coupler
Battery
Number of batteries supported: 1
Battery capacity: 9 Ah
Battery voltage: 12 V
Battery recharge time: 8 h
Charging current: 2 A
Other features
Input connection type: 4 x CEE 7/7, 3 x IEC C13
Logistics data
Harmonized System (HS) code: 85078000
UK Trade Tariff code: 85044085
Safety warning
Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water.
