Design
Fan connector: 4-pin
Base plate material: Copper
Fins material: Aluminium
Number of fans: 1 fan(s)
Number of heat pipes: 6
Product colour: Black
Power
Thermal Design Power (TDP): 95 W
Weight & dimensions
Height: 47 mm
Fan dimensions (W x D x H): 92 x 15 x 92 mm
Width: 140 mm
Heat pipes diameter: 6 mm
Depth: 120 mm
Weight: 407 g
Performance
Compatible processor series: Intel® Core™ i7, Intel® Pentium®, AMD A, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3
Suitable location: Processor
Noise level (high speed): 37.6 dB
Rotational speed (max): 2800 RPM
Type: Cooler
Bearing type: Fluid Dynamic Bearing (FDB)
Supported processor sockets: Socket FM1, Socket AM4, Socket AM3+, LGA 1156 (Socket H), LGA 1151 (Socket H4), Socket AM2+, Socket AM2, LGA 1155 (Socket H2), Socket AM3, LGA 1150 (Socket H3)
Rotational speed (min): 800 RPM
Noise level (low speed): 14 dB
Airflow: 80.03 m³/h
Fan diameter: 9.2 cm
Pulse-width modulation (PWM) support: Yes
Packaging content
Number of screws: 8
Mounting kit: Yes
Screws included: Yes
Other features
Heatsink dimensions (W x D x H): 140 x 120 x 47 mm
Thermal grease: Yes
Fan rated voltage: 12 V
Safety warning
Warnings: Do not touch the fan during operation.
