Features UPS topology: Line-Interactive Output power capacity: 1.2 kVA Output power: 650 W Input operation voltage (max): 300 V Audible alarm modes: Low battery alarm Surge energy rating: 273 J Output operation voltage (min): 230 V Response time: 6 ms Audible alarm(s): Yes Input frequency: 50/60 Hz Input operation voltage (min): 140 V Output operation voltage (max): 230 V Noise level: 40 dB Input power factor: 0.54 Automatic Voltage Regulation (AVR): Yes Waveform: Sine Output frequency regulation: 0.5 Hz Output frequency: 50/60 Hz Output voltage regulation: 10%
Design Form factor: Compact Product colour: Black International Protection (IP) code: IP20 LED indicators: Yes Cable length: 1.2 m
Operational conditions Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -15 - 40 °C Operating altitude: 0 - 3000 m Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Depth: 390 mm Weight: 7.6 kg Height: 190 mm Width: 140 mm
Packaging data Package width: 235 mm Package height: 297 mm Package depth: 495 mm Package weight: 8.6 kg
Packaging content Manual: Yes Cables included: Input power cable Management card included: No Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces SmartConnect port: No USB 2.0 ports quantity: 1 AC outlets quantity: 6 AC outlet(s) AC outlet types: C13 coupler Power plug: C14 coupler Ethernet LAN (RJ-45) ports: 2 USB port: Yes SmartSlot: No USB port type: USB Type-B
Battery Typical backup time at full load: 1 min Typical backup time at half load: 5 min Battery recharge time: 8 h Battery life (max): 2 year(s) Battery technology: Sealed Lead Acid (VRLA)
Logistics data Harmonized System (HS) code: 85078000
