Features Input operation voltage (max): 300 V Input frequency: 50/60 Hz Audible alarm modes: Low battery alarm Input operation voltage (min): 140 V Output operation voltage (min): 230 V Noise level: 40 dB Surge energy rating: 273 J UPS topology: Line-Interactive Output voltage regulation: 10% Output power capacity: 2.2 kVA Output power: 1200 W Output frequency regulation: 0.5 Hz Audible alarm(s): Yes Waveform: Sine Response time: 6 ms Input power factor: 0.54 Automatic Voltage Regulation (AVR): Yes Output frequency: 50/60 Hz Surge protection: Yes Output operation voltage (max): 230 V
Design LED indicators: Yes Form factor: Compact Product colour: Black Cable length: 1.2 m International Protection (IP) code: IP20
Operational conditions Storage temperature (T-T): -15 - 40 °C Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3000 m Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Width: 140 mm Height: 190 mm Depth: 390 mm Weight: 12.3 kg
Packaging data Package width: 235 mm Package height: 297 mm
Packaging content Cables included: Input power cable Manual: Yes Management card included: No Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces USB 2.0 ports quantity: 1 SmartSlot: No AC outlet types: Type F Power plug: Type F USB port type: USB Type-B AC outlets quantity: 4 AC outlet(s) USB port: Yes SmartConnect port: No
Battery Battery technology: Sealed Lead Acid (VRLA) Typical backup time at full load: 1 min Battery life (max): 2 year(s) Typical backup time at half load: 8.5 min Battery recharge time: 8 h
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water., Do not disassemble the unit housing, there may be a risk of electric shock.
