Features Output frequency regulation: 0.5 Hz Input power factor: 0.54 Automatic Voltage Regulation (AVR): Yes Waveform: Sine Input frequency: 50/60 Hz Output operation voltage (min): 230 V UPS topology: Line-Interactive Output voltage regulation: 10% Output power capacity: 2.2 kVA Audible alarm modes: Low battery alarm Input operation voltage (min): 140 V Surge energy rating: 273 J Output operation voltage (max): 230 V Input operation voltage (max): 300 V Output power: 1200 W Audible alarm(s): Yes Response time: 6 ms Surge protection: Yes Output frequency: 50/60 Hz Noise level: 40 dB
Design LED indicators: Yes Form factor: Compact Product colour: Black International Protection (IP) code: IP20 Cable length: 1.2 m
Operational conditions Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3000 m Storage temperature (T-T): -15 - 40 °C
Weight & dimensions Height: 190 mm Depth: 390 mm Width: 140 mm Weight: 12.3 kg
Packaging data Package height: 297 mm Package width: 235 mm
Packaging content Management card included: No Manual: Yes Cables included: Input power cable Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces SmartConnect port: No SmartSlot: No AC outlet types: C13 coupler Power plug: C19 coupler USB port type: USB Type-B USB 2.0 ports quantity: 1 AC outlets quantity: 6 AC outlet(s) USB port: Yes
Battery Typical backup time at half load: 8.5 min Battery recharge time: 8 h Battery life (max): 2 year(s) Battery technology: Sealed Lead Acid (VRLA) Typical backup time at full load: 1 min
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating.
