Features
Surge protection features: Modem, Digital Subscriber Line (DSL), Telephone, Fax
Audible alarm(s): Yes
Output power capacity: 0.35 kVA
Maximum current: 7 A
Surge protection: Yes
Efficiency: 98.6%
UPS topology: Standby (Offline)
Surge energy rating: 310 J
Audible alarm modes: Low battery alarm, Overload alarm
Hold time (max): 10 ms
Input frequency: 50/60 Hz
Output frequency regulation: 47 - 63 Hz
Power protection features: Overload
Input operation voltage (min): 180 V
Input operation voltage (max): 266 V
Hold time (min): 6 ms
Output power: 210 W
Design
Cable length: 1.83 m
Form factor: Tower
Product colour: Beige
LED indicators: Battery replacement
Operational conditions
Non-operating altitude: 0 - 15000 m
Storage temperature (T-T): -15 - 45 °C
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Weight & dimensions
Height: 165 mm
Depth: 284 mm
Width: 91 mm
Weight: 6.32 kg
Bundled software: PowerChute Serial Edition
Packaging data
Package height: 178 mm
Warranty card: Yes
Package width: 241 mm
Packaging content
Cables included: Phone (RJ-11), USB cable
Quick installation guide: Yes
Management card included: No
Certification: C-tick, CE, EN 50091-1, EN 50091-2,GOST, VDE, PEP, EOLI
Certificates
Compliance certificates: RoHS
Ports & interfaces
SmartSlot: No
AC outlet types: C13 coupler
USB port: Yes
Number of output IEC jumpers: 2
Power plug: C14 coupler
AC outlets quantity: 4 AC outlet(s)
SmartConnect port: No
Battery
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at full load: 8.6 min
Typical backup time at half load: 22.1 min
Battery life (max): 6 year(s)
Battery capacity: 116 VAh, 7 Ah
Battery recharge time: 6 h
Automatic battery test: Yes
Battery voltage: 12 V
Other features
Nominal output voltage: 230 V
Nominal input voltage: 230 V
Filtering: Yes
Logistics data
Harmonized System (HS) code: 85078000
Safety warning
Warnings: Keep away from sources of fire and water., Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating.
Sustainability
Sustainability certificates: ENERGY STAR, Green Premium
