Features Output power capacity: 0.5 kVA Efficiency: 96.1% UPS topology: Line-Interactive Surge protection: Yes Input operation voltage (max): 300 V Output power: 300 W Surge energy rating: 273 J Input operation voltage (min): 140 V Audible alarm modes: Alarm when on battery, Low battery alarm Input frequency: 50/60 Hz Noise level: 40 dB Audible alarm(s): Yes Automatic Voltage Regulation (AVR): Yes Waveform: Sine Input power factor: 0.63 Output frequency: 50/60 Hz
Design Product colour: Black LED indicators: Battery replacement Cable length: 1.5 m International Protection (IP) code: IP20 Form factor: Tower
Operational conditions Storage temperature (T-T): -15 - 40 °C Operating altitude: 0 - 3000 m Non-operating altitude: 0 - 3000 m Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 95% Storage relative humidity (H-H): 0 - 95%
Weight & dimensions Width: 98 mm Height: 138 mm Depth: 310 mm Weight: 4.2 kg
Packaging data Package weight: 4.5 kg Package depth: 346 mm Package height: 222 mm Package width: 142 mm Certification: CE, EAC, EN/IEC 62040-1
Certificates Compliance certificates: RoHS
Ports & interfaces Cabling technology: 10/100/1000Base-T(X) AC outlet types: C13 coupler Ethernet LAN (RJ-45) ports: 2 Number of output IEC jumpers: 1 Power plug: C14 coupler AC outlets quantity: 3 AC outlet(s)
Battery Battery technology: Sealed Lead Acid (VRLA) Battery recharge time: 8 h Automatic battery test: Yes Battery voltage: 12 V Battery life (max): 5 year(s)
Logistics data Harmonized System (HS) code: 85078000
