Features UPS topology: Line-Interactive Output power capacity: 0.95 kVA Audible alarm modes: Low battery alarm Noise level: 40 dB Surge protection: Yes Input frequency: 50/60 Hz Output operation voltage (min): 230 V Audible alarm(s): Yes Response time: 6 ms Surge energy rating: 273 J Output power: 520 W Input power factor: 0.54 Waveform: Sine Input operation voltage (max): 300 V Input operation voltage (min): 140 V Output operation voltage (max): 230 V Output frequency regulation: 0.5 Hz Output voltage regulation: 10% Automatic Voltage Regulation (AVR): Yes Output frequency: 50/60 Hz
Design LED indicators: Yes Form factor: Compact International Protection (IP) code: IP20 Cable length: 1.2 m Product colour: Black
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3000 m Storage temperature (T-T): -15 - 40 °C Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Height: 160 mm Weight: 6.1 kg Width: 120 mm Depth: 355 mm
Packaging data Package height: 250 mm Package width: 197 mm
Packaging content Cables included: Input power cable Manual: Yes Management card included: No Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces Ethernet LAN (RJ-45) ports: 2 AC outlet types: Type F USB 2.0 ports quantity: 1 SmartConnect port: No AC outlets quantity: 4 AC outlet(s) USB port: Yes Power plug: Type F SmartSlot: No USB port type: USB Type-B
Battery Typical backup time at half load: 6.5 min Battery technology: Sealed Lead Acid (VRLA) Typical backup time at full load: 1 min Battery recharge time: 8 h Battery life (max): 2 year(s)
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water.
