Features Output power capacity: 0.95 kVA Output operation voltage (max): 230 V Input power factor: 0.54 Automatic Voltage Regulation (AVR): Yes Audible alarm modes: Low battery alarm Waveform: Sine Input operation voltage (max): 300 V Audible alarm(s): Yes Output voltage regulation: 10% Output operation voltage (min): 230 V Response time: 6 ms Output frequency regulation: 0.5 Hz Output power: 520 W Output frequency: 50/60 Hz Input operation voltage (min): 140 V Noise level: 40 dB UPS topology: Line-Interactive Input frequency: 50/60 Hz Surge protection: Yes Surge energy rating: 273 J
Design International Protection (IP) code: IP20 LED indicators: Yes Cable length: 1.2 m Form factor: Compact Product colour: Black
Operational conditions Operating relative humidity (H-H): 0 - 95% Operating altitude: 0 - 3000 m Storage temperature (T-T): -15 - 40 °C Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 355 mm Width: 120 mm Weight: 6.1 kg Height: 160 mm
Packaging data Package width: 197 mm Package depth: 430 mm Package height: 250 mm Package weight: 6.6 kg
Packaging content Management card included: No Manual: Yes Cables included: Input power cable Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces USB port type: USB Type-B SmartSlot: No Power plug: C14 coupler Ethernet LAN (RJ-45) ports: 2 USB port: Yes AC outlet types: C13 coupler AC outlets quantity: 6 AC outlet(s) USB 2.0 ports quantity: 1 SmartConnect port: No
Battery Battery life (max): 2 year(s) Typical backup time at full load: 1 min Typical backup time at half load: 6.5 min Battery technology: Sealed Lead Acid (VRLA) Battery recharge time: 8 h
Logistics data Harmonized System (HS) code: 85078000
