Features
Noise level: 45 dB
Surge protection features: Telephone, Modem, Digital Subscriber Line (DSL), Fax
Output power: 400 W
Hold time (max): 10 ms
Audible alarm(s): Yes
Waveform: Sine
Output power capacity: 0.65 kVA
Surge protection: Yes
UPS topology: Standby (Offline)
Efficiency: 98.9%
Maximum current: 7 A
Audible alarm modes: Low battery alarm, Overload alarm
Input frequency: 50/60 Hz
Surge energy rating: 310 J
Input operation voltage (max): 286 V
Hold time (min): 6 ms
Input operation voltage (min): 160 V
Output frequency regulation: 47 - 63 Hz
Design
Cable length: 1.8 m
Product colour: Beige
Form factor: Tower
LED indicators: Yes
Operational conditions
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Operating altitude: 0 - 3048 m
Non-operating altitude: 0 - 15240 m
Weight & dimensions
Width: 91 mm
Weight: 6.03 kg
Height: 165 mm
Depth: 284 mm
Bundled software: PowerChute Serial Edition
Packaging data
Package width: 185 mm
Package weight: 7.31 kg
Package depth: 415 mm
Software CD: Yes
Package height: 494 mm
Packaging content
Cables included: USB cable
Quick installation guide: Yes
Management card included: No
Certification: A-tick, C-tick, CE, GOST, NEMKO
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlets quantity: 4 AC outlet(s)
AC outlet types: C13 coupler
USB port: Yes
Power plug: C14 coupler
Number of output IEC jumpers: 2
SmartSlot: No
SmartConnect port: No
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery voltage: 12 V
Replacement battery cartridge: 1
Automatic battery test: Yes
Battery life (max): 6 year(s)
Battery capacity: 9 Ah, 111 VAh
Typical backup time at half load: 14.7 min
Typical backup time at full load: 4.7 min
Battery recharge time: 8 h
Other features
Filtering: Yes
Nominal output voltage: 230 V
Nominal input voltage: 230 V
Logistics data
Products per master (outer) case: 1 pc(s)
Harmonized System (HS) code: 85078000
Products per pallet: 48 pc(s)
Sustainability
Sustainability certificates: ENERGY STAR, Green Premium
