Features Input operation voltage (max): 280 V Input operation voltage (min): 170 V Number of input phases: 1 Output power: 600 W Transfer time (Line Mode to Battery Mode): 6 ms Number of output phases: 1 Audible alarm modes: Alarm when on battery, Low battery alarm, Overload alarm Surge energy rating: 156 J Waveform: Sine UPS topology: Line-Interactive Audible alarm(s): Yes Output power capacity: 1 kVA Noise level: 40 dB Output frequency: 50/60 Hz Surge protection: Yes Input frequency: 50/60 Hz Automatic Voltage Regulation (AVR): Yes
Design Form factor: Compact International Protection (IP) code: IP20 LED indicators: Yes Product colour: Black Cable length: 1.52 m
Operational conditions Operating altitude: 0 - 2032.1 m Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90%
Weight & dimensions Width: 160.5 mm Height: 92.5 mm Depth: 305 mm Weight: 5.7 kg
Packaging data Package height: 237 mm Package width: 373 mm
Packaging content Management card included: No Certification: CE
REACH
Certificates Compliance certificates: RoHS
Ports & interfaces AC outlets quantity: 4 AC outlet(s) SmartSlot: No AC outlet types: Type F SmartConnect port: No
Battery Battery voltage: 12 V Battery technology: Sealed Lead Acid (VRLA) Battery capacity: 9 Ah Cold start: Yes Battery recharge time: 8 h
Other features Nominal output voltage: 230 V
Logistics data Harmonized System (HS) code: 85078000 Warranty period: 2 year(s)
