Features Output operation voltage (min): 230 V Surge energy rating: 273 J UPS topology: Line-Interactive Input power factor: 0.54 Automatic Voltage Regulation (AVR): Yes Input frequency: 50/60 Hz Output voltage regulation: 10% Output power capacity: 1.2 kVA Input operation voltage (min): 140 V Waveform: Sine Audible alarm modes: Low battery alarm Input operation voltage (max): 300 V Audible alarm(s): Yes Noise level: 40 dB Output frequency regulation: 0.5 Hz Output power: 650 W Output operation voltage (max): 230 V Output frequency: 50/60 Hz Surge protection: Yes Response time: 6 ms
Design Form factor: Compact International Protection (IP) code: IP20 Product colour: Black Cable length: 1.2 m LED indicators: Yes
Operational conditions Storage temperature (T-T): -15 - 40 °C Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3000 m
Weight & dimensions Width: 140 mm Depth: 390 mm Height: 190 mm Weight: 7.6 kg
Packaging data Package width: 235 mm Package height: 297 mm
Packaging content Cables included: Input power cable Manual: Yes Management card included: No Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces AC outlet types: Type F USB port type: USB Type-B Power plug: Type F SmartSlot: No USB port: Yes SmartConnect port: No USB 2.0 ports quantity: 1 Ethernet LAN (RJ-45) ports: 2 AC outlets quantity: 4 AC outlet(s)
Battery Battery life (max): 2 year(s) Typical backup time at half load: 5 min Battery technology: Sealed Lead Acid (VRLA) Typical backup time at full load: 1 min Battery recharge time: 8 h
Logistics data Harmonized System (HS) code: 85078000
