Features Output operation voltage (max): 230 V Input frequency: 50/60 Hz Audible alarm modes: Low battery alarm Response time: 6 ms UPS topology: Line-Interactive Output operation voltage (min): 230 V Output power capacity: 2.2 kVA Input operation voltage (max): 300 V Input power factor: 0.54 Automatic Voltage Regulation (AVR): Yes Surge energy rating: 273 J Input operation voltage (min): 140 V Audible alarm(s): Yes Waveform: Sine Noise level: 40 dB Output power: 1200 W Output frequency regulation: 0.5 Hz Output voltage regulation: 10% Surge protection: Yes Output frequency: 50/60 Hz
Design Form factor: Compact International Protection (IP) code: IP20 LED indicators: Yes Cable length: 1.2 m Product colour: Black
Operational conditions Operating altitude: 0 - 3000 m Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 95% Storage temperature (T-T): -15 - 40 °C
Weight & dimensions Width: 140 mm Depth: 390 mm Height: 190 mm Weight: 12.3 kg
Packaging data Package height: 297 mm Package weight: 13.3 kg Package width: 235 mm Package depth: 495 mm
Packaging content Cables included: Input power cable Manual: Yes Management card included: No Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces Power plug: Type F AC outlet types: Type F USB 2.0 ports quantity: 1 AC outlets quantity: 4 AC outlet(s) USB port: Yes USB port type: USB Type-B SmartSlot: No SmartConnect port: No
Battery Typical backup time at full load: 1 min Battery recharge time: 8 h Typical backup time at half load: 8.5 min Battery technology: Sealed Lead Acid (VRLA) Battery life (max): 2 year(s)
Logistics data Harmonized System (HS) code: 85078000
